Side 1/2

KONFTEL.COM

Konftel Video Solutions

with Konftel Cam20

INSTALLATION GUIDE

Installation guide

Konftel Cam20 video kits

900103305

Konftel AB, Box 268, SE-901 06 Umeå, Sweden

Tel: +46 90 70 64 89 E-mail: info@konftel.com

KONFTEL.COM

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

HOW IT WORKS

WHAT YOU NEED

2. Connect the USB cable

and wait until conﬁguration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Laptop with the

collaboration app

Konftel OCC

USB cable

Konftel is a leading company within collaboration endpoint solutions. Since 1988, our

mission has been to help people in businesses around the world to have meetings

regardless of distance. We know that remote collaboration is an effective way to save time,

money and contribute to a more sustainable world.

We are Climate Neutral Certified, offering customers an option to purchase conferencing

equipment while keeping a clear climate conscience. Crystal clear audio and a sharp video

image are essential for efficient meetings; this is why we only focus on cutting-edge

technology in our Collaboration Solutions. Our audio technology OmniSound

is built

into all Konftel Conference phones and devices. The products are sold globally under

the Konftel brand and our headquarters are based in Sweden.

Read more about the company and our products at konftel.com.

Good goods!

Konftel is a Climate Neutral certified company. We have measured and offset our

entire footprint of greenhouse gases, and are committed to reduce our emissions.

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

Connect to power outlet

Make sure to connect the Konftel 70 and

Konftel 55/55Wx to a power outlet.

HOW IT WORKS

WHAT YOU NEED

2. Connect the USB cable

and wait until conﬁguration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

PACKING LIST

Konftel Cam20

• USB cable

• Remote control with two

AAA batteries

• Quick guide and Safety declaration

Konftel Ego

• USB cable (to be replaced by )

• Soft case

• Quick guide and Safety declaration

Konftel 70

• USB cable (to be replaced by )

• Power cable

• AC adapter

• Quick guide and Safety declaration

Konftel 55

• USB cable (to be replaced by )

• Power cable

• AC adapter

• Safety declaration

Konftel 55Wx

• USB cable (to be replaced by )

• Power cable

• AC adapter

• Battery

• Safety declaration

Konftel OCC Hub

• USB cable (Konftel Ego/

Konftel 70)

• USB cable (Konftel 55-series)

• USB cable (laptop)

• AC adapter

• Velcro tape (for mounting of

OCC hub)

• Quick guide and Safety declaration

Konftel C20Ego | 951201081

Konftel C2070 | 951201089

931201001 900102149

Konftel C2055 | 951201071

Konftel C2055Wx | 951201082

1. CAMERA 2. HUB

3. AUDIO

One of the following audio devices is included in this video kit.

INSTALLATION

HDMI cable

(not included)

After installation, tear off next page and place it on the table next to the orange cable.

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Laptop with the

collaboration app

Konftel OCC

USB cable

Connect the

screen to the lap-

top if you can’t

run DisplayLink.

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Videokonferansesystem
Modell:	C2070
Produkttype:	Gruppevideokonferansesystem
Vekt:	2070 g
Bruksanvisning:	Ja
Bluetooth:	Ja
Bluetooth-versjon:	4.2
USB-kontakttype:	Micro-USB B
Maksimal bildefrekvens:	30 fps
Pakkevekt:	3040 g
Produktmål:	280 x 250 x 53 mm
Antall USB 2.0-porter:	1
Sertifisering:	EMC: 2014/30/EU, EMC Regulations 2016, LVD: 2014/35/EU, Electrical Equipment (Safety) Regulations 2016, WEEE: 2012/19/EC, RoHS: 2011/65/EU, REACH: EC 1907/2006
Digital zoom:	8 x
Maksimal videooppløsning:	- piksler
Støyreduksjon:	Ja
Antall mikrofoner:	4
Mikrofonretningstype:	Retningsuavhengig
Antall personer:	- person(er)
AC-inngangsspenning:	100 - 240 V
Kameravekt:	340 g
Synsfelt:	123 °
Diagonalt synsfelt:	123 °
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	370 mm
Pakkehøyde:	200 mm
Pakkebredde:	305 mm
Støttede grafikkoppløsninger:	3840 x 2160
Kabler inkludert:	USB Type-A til USB Type-B
Støttede videofunksjoner:	2160p
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	Low Voltage Directive (LVD), REACH, RoHS, WEEE
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Megapiksel:	- MP
Justering av fokus:	Automatisk
Oppløsning ved innspillingshastighet:	3840x2160@30fps
Mikrofonens opptaksrekkevidde:	4 m
Relativ luftfuktighet under drift (H-H):	20 - 80
AC-adapter bunt:	Ja
Videoformat som støttes:	H.264, MJPG, YUY2
Ekkokansellering:	Ja
Bildesensor størrelse:	- "
Kamera inkludert:	Ja
Kamera dimensioner (BxDxH):	194 x 34 x 42 mm
Høyttaler vekt:	700 g
Kamerakontrollenhet medfølger:	Ja
