Side 1/2

KONFTEL.COM

Konftel is a leading company within collaboration endpoint solutions.

Since 1988, our mission has been to help people in businesses around the

world to have meetings regardless of distance. Based on our success,

we know that remote collaboration is a smooth way to save time,

money and at the same time contribute to a more sustainable world.

Crystal clear audio and a sharp video image are essential for efficient meetings,

this is why we only focus on cutting-edge technology in our Collaboration Solutions.

Our audio technology OmniSound

is built into all Konftel Conference

phones and devices. The products are sold globally under the Konftel brand

and our headquarter is based in Sweden.

Read more about the company and our products at konftel.com.

Konftel AB, Box 268, SE-901 06 Umeå, Sweden

Tel: +46 90 70 64 89 E-mail: info@konftel.com

KONFTEL.COM

Good goods!

Konftel is a Climate Neutral certified company. We have measured and offset our

entire footprint of greenhouse gases, and are committed to reduce our emissions.

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

HOW IT WORKS

WHAT YOU NEED

Laptop with the

collaboration app

Konftel OCC

USB cable

2. Connect the USB cable

and wait until configuration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Konftel C50800 Hybrid

and C20800 Hybrid

INSTALLATION GUIDE

Installation guide

Konftel 800 Hybrid video kit

900103312

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

Connect to PoE

Connect the network cable to an existing network

with PoE support or use the supplied PoE Injector kit.

HOW IT WORKS

WHAT YOU NEED

2. Connect the USB cable

and wait until configuration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

INSTALL ATION

After installation, tear off next page and place it on the table next to the orange cable.

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Connect the

HDMI cable to

the laptop if

you can’t run

DisplayLink.

Laptop with the

collaboration app

Konftel OCC

USB cable

PACKING LIST

Konftel 800

• USB cable (to be replaced by

)

• Network cable

• Get started guide

• Safety declaration

Konftel PoE-Injector kit

• Power cable

• Network cable

• Safety declaration

Konftel OCC Hub

• USB cable

(Konftel 800/Konftel Ego)

• USB cable

(Konftel 55/300-series)

• USB cable

(laptop)

• AC adapter

• Velcro

• Quick guide and Safety declaration

910101088

900102149

900102150 / 902102150

903102150 / 804102150

1. CAMERA

4. HUB

2. AUDIO 3. POE INJECTOR

Konftel Cam50

• USB cable

• AC adapter

• Remote control with two AAA

batteries

• Wall mount

• Quick guide and Safety declaration

931401002 / 932401002

933401002 / 834401002

HDMI cable

(not included)

Konftel Cam20

• USB cable

• Remote control with two

AAA batteries

• Quick guide and Safety declaration

931201001

One of the following cameras is included in this video kit.

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Videokonferansesystem
Modell:	C20800 Hybrid
Produkttype:	Gruppevideokonferansesystem
Innebygd skjerm:	Ja
Vekt:	2800 g
Bruksanvisning:	Ja
Bluetooth:	Ja
Berøringsskjerm:	Ja
Bluetooth-versjon:	4.1
USB-kontakttype:	USB Type-B
Maksimal bildefrekvens:	30 fps
Pakkevekt:	3840 g
Produktmål:	326 x 370 x 75 mm
Sertifisering:	EMC: 2014/30/EU, EMC Regulations 2016, LVD: 2014/35/EU, Electrical Equipment (Safety) Regulations 2016, WEEE: 2012/19/EC, RoHS: 2011/65/EU, REACH: EC 1907/2006
Digital zoom:	8 x
Maksimal videooppløsning:	- piksler
Støyreduksjon:	Ja
Nettverksstandard:	IEEE 802.3af, IEEE 802.3at
Antall mikrofoner:	3
Mikrofonretningstype:	Retningsuavhengig
Antall personer:	- person(er)
AC-inngangsspenning:	100 - 240 V
Skjermoppløsning:	480 x 800 piksler
Utgangsnivå:	0/95 dB
Synsfelt:	123 °
Diagonalt synsfelt:	123 °
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	480 mm
Pakkehøyde:	220 mm
Pakkebredde:	395 mm
Skjermdiagonal:	4.3 "
Støttede grafikkoppløsninger:	3840 x 2160
Kabler inkludert:	AC, LAN (RJ-45), USB Type-A to USB Type-B
Støttede videofunksjoner:	2160p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	Low Voltage Directive (LVD), REACH, RoHS, WEEE
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Megapiksel:	- MP
Justering av fokus:	Automatisk
Oppløsning ved innspillingshastighet:	3840x2160@30fps
Mikrofonens opptaksrekkevidde:	6 m
Strøm:	4 A
OSD-språk:	DAN, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POR, SWE
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Støttede Windows operativsystemer:	Windows 10 Education, Windows 7, Windows 8
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 80
Kabellåsport:	Ja
Kabellåstype:	Kensington
AC-adapter bunt:	Ja
Videoformat som støttes:	H.264, MJPG, YUY2
Power over Ethernet (PoE)-ports, antall:	1
Stemmekodekser:	G.711, G.722, G.729, iLBC
DC inngående spenning:	5 V
Ekkokansellering:	Ja
Bildesensor størrelse:	- "
Frekvensrekkevidde:	100 - 20000 Hz
Kamera inkludert:	Ja
Nettverkskabelens lengde:	6.5 m
Høyttaler vekt:	1400 g
