Side 1/2

KONFTEL.COM

Konftel is a leading company within collaboration endpoint solutions.

Since 1988, our mission has been to help people in businesses around the

world to have meetings regardless of distance. Based on our success,

we know that remote collaboration is a smooth way to save time,

money and at the same time contribute to a more sustainable world.

Crystal clear audio and a sharp video image are essential for efficient meetings,

this is why we only focus on cutting-edge technology in our Collaboration Solutions.

Our audio technology OmniSound

is built into all Konftel Conference

phones and devices. The products are sold globally under the Konftel brand

and our headquarter is based in Sweden.

Read more about the company and our products at konftel.com.

Konftel AB, Box 268, SE-901 06 Umeå, Sweden

Tel: +46 90 70 64 89 E-mail: info@konftel.com

KONFTEL.COM

Good goods!

Konftel is a Climate Neutral certified company. We have measured and offset our

entire footprint of greenhouse gases, and are committed to reduce our emissions.

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

HOW IT WORKS

WHAT YOU NEED

Laptop with the

collaboration app

Konftel OCC

USB cable

2. Connect the USB cable

and wait until configuration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Konftel C50800 Hybrid

and C20800 Hybrid

INSTALLATION GUIDE

Installation guide

Konftel 800 Hybrid video kit

900103312

All our video kits supports Konftel One Cable Connection, so a single

USB cable is all you need to connect the camera, the speakerphone

and the room’s screen to the collaboration app on your laptop.

VIDEO MEETINGS WITH KONFTEL

1. Before connecting the

orange cable to your laptop,

make sure you have the

DisplayLink driver installed.

Download driver at

konftel.com/occ

Connect to PoE

Connect the network cable to an existing network

with PoE support or use the supplied PoE Injector kit.

HOW IT WORKS

WHAT YOU NEED

2. Connect the USB cable

and wait until configuration

is completed. (The ﬁrst time, it

might take up to 60 seconds.)

FIRST TIME

INSTALL ATION

After installation, tear off next page and place it on the table next to the orange cable.

3. In your collaboration app

(for example Microsoft Teams

or Zoom), go to settings and

select Konftel for both audio

and camera.

Connect the

HDMI cable to

the laptop if

you can’t run

DisplayLink.

Laptop with the

collaboration app

Konftel OCC

USB cable

PACKING LIST

Konftel 800

• USB cable (to be replaced by

)

• Network cable

• Get started guide

• Safety declaration

Konftel PoE-Injector kit

• Power cable

• Network cable

• Safety declaration

Konftel OCC Hub

• USB cable

(Konftel 800/Konftel Ego)

• USB cable

(Konftel 55/300-series)

• USB cable

(laptop)

• AC adapter

• Velcro

• Quick guide and Safety declaration

910101088

900102149

900102150 / 902102150

903102150 / 804102150

1. CAMERA

4. HUB

2. AUDIO 3. POE INJECTOR

Konftel Cam50

• USB cable

• AC adapter

• Remote control with two AAA

batteries

• Wall mount

• Quick guide and Safety declaration

931401002 / 932401002

933401002 / 834401002

HDMI cable

(not included)

Konftel Cam20

• USB cable

• Remote control with two

AAA batteries

• Quick guide and Safety declaration

931201001

One of the following cameras is included in this video kit.

Produkspesifikasjoner

Merke:	Konftel
Kategori:	Videokonferansesystem
Modell:	C50800 Hybrid
Produkttype:	Gruppevideokonferansesystem
Innebygd skjerm:	Ja
Vekt:	3720 g
Bredde:	326 mm
Dybde:	370 mm
Høyde:	75 mm
Bruksanvisning:	Ja
Bluetooth:	Ja
Berøringsskjerm:	Ja
Bluetooth-versjon:	4.1
USB-kontakttype:	Micro-USB B, USB Type-A
Maksimal bildefrekvens:	60 fps
Pakkevekt:	5620 g
Sertifisering:	UL 60950-1 2nd, CAN/CSA-C22.2 NO. 60950-1-07, EN 60950-1:2006+A1+A2, AS/NZ 60950-1\nFCC 15 B, ICES-003 B, EN 55032:2010 B, EN 55024\nCE, UL, NOM, CCC, PSE, KETI, A-TICK, EAC, SABS, BSMI, BIS, PSB
Optisk zoom:	12 x
Maksimal videooppløsning:	- piksler
Antall mikrofoner:	3
Støttede nettverksprotokoller:	IEEE 802.3af/at, 802.1x
Mikrofonretningstype:	Retningsuavhengig
PTZ-kontroll:	Ja
Antall personer:	20 person(er)
AC-inngangsspenning:	100 - 240 V
Skjermoppløsning:	480 x 800 piksler
Synsfelt:	72.5 °
Diagonalt synsfelt:	72.5 °
Produktfarge:	Sort
HD-type:	Full HD
Vippevinkelområde:	0 - 60 °
Pakkedybde:	480 mm
Pakkehøyde:	375 mm
Pakkebredde:	410 mm
Skjermdiagonal:	4.3 "
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Kabler inkludert:	LAN (RJ-45), USB
Støttede videofunksjoner:	1080p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	Low Voltage Directive (LVD), REACH, RoHS, WEEE
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Megapiksel:	2 MP
Justering av fokus:	Automatisk
Oppløsning ved innspillingshastighet:	1920x1080@60fps
Panoreringsomfang:	0 - 170 °
Mikrofonens opptaksrekkevidde:	6 m
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	EAP-TLS, HTTPS
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 80
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	1
Kabellåsport:	Ja
Kabellåstype:	Kensington
AC-adapter bunt:	Ja
Videoformat som støttes:	H.264, MJPG, YUY2
Power over Ethernet (PoE)-ports, antall:	1
Stemmekodekser:	G.711, G.711alaw, G.711ulaw, G.722, G.729, OPUS, iLBC
Bildesensor størrelse:	1/2.7 "
Frekvensrekkevidde:	80 - 14000 Hz
Antall kameraforhåndsinnstillinger:	255
Antall RJ11-porter:	2
PoE-adapter inkludert:	Ja
Kamera inkludert:	Ja
Kamerakabellengde (maks.):	5 m
