Table of Content

English ...........................................................................................................- 2 -

Deutsch ..........................................................................................................- 6 -

Français .......................................................................................................- 10 -

Español ........................................................................................................- 14 -

Italiano.........................................................................................................- 18 -

 .......................................................................................................- 22 -

Português.....................................................................................................- 26 -

简体中文 ......................................................................................................- 30 -

This Quick Installation Guide only describes the most basic situations and settings. All

detailed information is described in the user manual.

- 2 -

English

Package Contents

This product is provided with the following accessories in the box; please check them carefully. If

any of the accessories is missing or damaged, please contact with your local dealer timely.

Serial

number

Name

Quantity

Note

Master unit

Required

Power cord

Required

Quick Installation Guide

Required

L-shaped bracket and other

Required

CD-ROM with Manual and QIG

Required

1. Preparing for installation

For smooth installation, please prepare the following items:

 Installation tools, including: Phillips screwdriver, anti static wrist strap, etc.

 Connecting cables, such as network cable, optical fiber, optical fiber module, etc.

 Related devices, such as electrical outlets, HUB, switch, router, etc.

The installation environment for the switch must meet the following requirements:

1. The switch must avoid direct sunlight, away from heat and sources of strong electromagnetic interference.

2. The switch must be placed in a cool, dry place, and there should be enough gap for heat dissipation all

around for the purpose of ventilation and heat dissipation.

3. The switch must work in the indoor environment with a temperature of 0 °C~40 °C and humidity of 10%~90%

without condensation.

Produkspesifikasjoner

Merke:	LevelOne
Kategori:	Bryter
Modell:	GEL-5261
Vekt:	2500 g
Bredde:	440 mm
Dybde:	220 mm
Høyde:	44 mm
Støynivå:	54.2 dB
LED-indikatorer:	Activity, Link, Power
Opprinnelsesland:	China
Pakkevekt:	3300 g
Sertifisering:	CE class A, FCC, UL, VCCI, BSMI
Internminne:	32 MB
Nettverksstandard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Støttede nettverksprotokoller:	IPv6, IPv4
MAC-adressefiltrering:	Ja
Virtuelle LAN-funksjoner:	Tagged VLAN, MAC address-based VLAN, Port-based VLAN
10G støtte:	Nei
Multicast-støtte:	Ja
Konsollport:	RJ-45
Portspeiling:	Ja
DHCP-funksjoner:	DHCP snooping, DHCP relay, DHCP client
Varmespredning:	136.48 BTU/t
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Jumbo rammer:	10000
Systemhendelseslogg:	Ja
Antall køer:	8
Autentisering:	MAC-basert autentisering
Telnet:	Ja
Produktfarge:	Sort
Pakkedybde:	80 mm
Pakkehøyde:	405 mm
Pakkebredde:	580 mm
Kabler inkludert:	AC, LAN (RJ-45)
Pakketype:	Boks
Strømforbruk (vanlig bruk):	20 W
Driftstemperatur (T-T):	0 - 50 °C
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Quality of Service (QoS) støtte:	Ja
tilbakestillingsknapp:	Ja
Oppgraderbar fastvare:	Ja
Ressurs-CD:	Ja
Ethernet-kobberkabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Relativ luftfuktighet under drift (H-H):	10 - 90
Rack-montering:	Ja
Ledelsesprotokoller/håndteringsprotokoller:	NTP/SNTP/HTTP/TFTP/FTP/Telent/SSH
Gjennomsnittstid mellom feil (MTBF):	534057 timer
Svitsjtype:	Håndtert
Trafikk klassifisering:	Ja
Webbasert administrasjon:	Ja
Antall Basic switching RJ-45 Ethernet-ports:	48
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Strømningskontroll støtte:	Ja
Størrelse på adressetabell:	16000 oppføringer
Ruting/svitsjekapasitet:	104 Gbit/s
IGMP-snooping:	Ja
Plugg inn og spill:	Ja
Jumbo Frames-støtte:	Ja
Masterkassens (ytterkassens) bruttovekt:	14300 g
Masterkassens (ytterkassens) lengde:	340 mm
Produkter per masterkasse (ytterkasse):	4 stykker
Masterkassens (ytterkassens) bredde:	600 mm
Masterkassens (ytterkassens) høyde:	435 mm
VLAN støtte:	Ja
Lagre-og-videresend:	Ja
Bufferminne pakke:	12 MB
Videresendingshastighet:	77.4 Mpps
Rack-montert sett:	Ja
DoS-angrepsbeskyttelse:	Ja
SFP module antall spor:	4
Strømbryterbelegg:	L3
Omfangsbegrensning:	Ja
Access Control List (ACL)/tilgangskontrolliste:	Ja
Statisk ruting:	Ja
Linkaggregasjon/Linksamling:	Ja
Treprotokoll (spekter):	Ja
SSH/SSL støtte:	Ja
IPv4- og IPv6-funksjoner:	IPv6 ping, IPv6 tracert, IPv6 Telnet
Clusterstøtte:	Ja
