Side 1/5
1
7/30/24
IES-0620 6-Port Gigabit PoE
Industrial Switch, 802.3at/af
PoE, 4 PoE Outputs, 1 x SFP, 1
x SFP/RJ45 Combo, DIN-Rail,
-40°C to 75°C, 126W, voltage
booster
Product Images
2
7/30/24
Short Description
4 Gigabit PoE ports, 1 Gigabit SFP slot and 1 Gigabit RJ45/SFP Combo port
Total PoE power budget: 126W, up to 30W per port
-40°C to 75°C operating temperature range
IP30 metal case
Supports 12 to 55V DC power inputs
Redundant power inputs with Terminal Block
Description
LevelOne IES-0620 Industry Ethernet Switch provides 4 PoE ports 10/100/1000Base plus
2 port Gigabit SFP to enable high speed network at mission-critical environment. With the
industrial standard DIN-rain mount; this switch can be easily installed in the cabinet, plus
the clearly visible status LEDs provide simple monitoring of port link activity. Moreover,
the SFP slots support pluggable modules that enabling you to choose from a variety of
transceivers. This switch is Power Sourcing Equipment (PSE), and it is fully complied with
IEEE 802.3at PoE standard at maximum 30W power budget per port. It helps to save
infrastructure wiring costs dramatically by eliminating electric wiring and less UPS
needed. Also, it is compatible with IEEE802.3af standard PD devices.
3
7/30/24
Additional Information
Knob
DIP1 On : Port 5 supports TX Copper DIP1 O :
Port 5 supports SFP (Default) DIP2 : Reserved
Gigabit SFP x 2
802.3af/at PoE x 6
Color Black
EAN 4015867188514
Model Number IES-0620
Data rate Gigabit Ethernet
PoE Power Budget Total 126.00
PoE Supported Yes
Concurrent ports Total 6.00
Fanless Yes
Manageable No
Grade Industrial
Approval and Compliance
FCC Part 15 Subpart B Class A CE VCCI
EN60950-1 EN61000-4-2 (ESD) Level 3
EN61000-4-3 (RS) Level 3 EN61000-4-4 (EFT)
Level 3 EN61000-4-5 (Surge) Level 3
EN61000-4-6 (CS) Level 3 EN61000-4-8 (Magnetic
Field) Level 3 UL508 (Pending) EN 50121-4
(Pending) IEC 60068-2-27 IEC 60068-2-32 IEC
60068-2-6 UL 508
Operating humidity 5% RH ~ 95% RH
Operating temperature -40°C ~ 75°C
Storage humidity 5% RH ~ 95% RH
Storage temperature -40°C ~ 85°C
Package Contents IES-0620 Quick Installation Guide
Dimensions (W x D x H) 40 x 105 x 38 mm
Product weight (kg) 0,72
Backplane (Gbps) 12
