Side 1/60

Español 13 • Français 25 • Deutsch 37 • Italiano 49

Owner’s Manual

Purchased product

may differ from image.

B118-002-HDR,

B118-002-HDR-V2,

B118-004-HDR

UHD 4K x 2K (2160p) @

60 Hz HDMI Splitters with

Multi-Resolution Support

23-09-085-933935.indb 123-09-085-933935.indb 1 10/18/2023 2:48:34 PM10/18/2023 2:48:34 PM

Product Features

• SimultaneouslytransmitUltraHighDenitionvideoandaudiofroman

HDMI source to multiple HDMI monitors

• SupportsUHD4Kx2Kvideoresolutionsupto4096x2160@60Hz

4:4:4

• Backwardcompatiblewith4K/30Hzand1080p/60Hzresolutionsvia

AutoDIPSwitching(idealforinstallationswhereequipmentvaries)

• Supports36-bitDeepColor(12bitsperchannel)

• Supports DTS-HD™, Dolby

TrueHD,DolbyDigitalPlus™andLPCM

7.1ChannelSurroundSoundaudio

• Supportsvideoamplierbandwidthof600MHz/6Gbpsperchannel

(18Gbpstotal)

• HDMI2.0,HDCP2.2,MHL2.2andHDRcompatible

• Supports Full 3D and EDID

• Supports lip sync and audio pass through

• SupportsxvYCCandx.vColor

• Distributesvideoandaudiooveramaximumdistanceof15ft.(4m)

whenusedwithstandard28AWGHDMI2.0cable

• B118-002-HDR and B118-004-HDR Models:Cascadeupto3levels

ofsplitterstoincreaseupto64connectedmonitors.

• Versatile design allows for both desktop and wall-mount use

• Plug-and-play;nosoftwareordriversrequired

• Includes an international power supply with compatible North

American, U.K., European and Australian plug adapters

23-09-085-933935.indb 223-09-085-933935.indb 2 10/18/2023 2:48:34 PM10/18/2023 2:48:34 PM

Package Contents

B118-002-HDR & B118-004-HDR:

• ExternalPowerSupply*(Input:100-240V,50/60Hz,0.35A;

Output:5V2A)

• Owner’s Manual

*IncludesNEMA1-15P(NorthAmerica),CEE7/16Schuko(Europe),BS1363(U.K.)

andAS/NZS3112(Australia)plugs.

B118-002-HDR-V2:

• USBCable

• Owner’s Manual

• P569-003-CERTPremiumHigh-SpeedHDMICable—3ft.(0.91m)

• P569-006-CERTPremiumHigh-SpeedHDMICable—6ft.(1.83m)

• P569-010-CERTPremiumHigh-SpeedHDMICable—10ft.(3.05m)

• P569-015-CERTPremiumHigh-SpeedHDMICable—15ft.(4.6m)

Optional Accessories

23-09-085-933935.indb 323-09-085-933935.indb 3 10/18/2023 2:48:34 PM10/18/2023 2:48:34 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Splitter
Modell:	B118-004-HDR
Vekt:	360 g
Bredde:	128 mm
Dybde:	100 mm
Høyde:	29.7 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Maksimal oppløsning:	4096 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	500 g
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
3D:	Ja
HDMI-versjon:	2.0
Fargedybde:	36 bit
Utgangsstrøm:	2 A
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Antall videoporter:	5
Kabellengde:	1.2 m
Produktfarge:	Sort
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	260.1 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85176990
Kroppsmateriale:	Metall
Video ut:	4x HDMI
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Kontaktplettering:	Nickel
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332238020
Masterkassens (ytterkassens) bruttovekt:	5400 g
Masterkassens (ytterkassens) lengde:	273 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Innput-strøm:	0.35 A
Video tilkoblingstype:	HDMI
