Side 1/120

HDMI over Cat6

Splitter Kits, 4K/60 Hz

Splitter Models: B127A-002-BH,

B127A-004-BH, B127A-008-BH

Splitter and Receiver Kit Models:

B127A-002-BHPH2, B127A-004-BHPH3

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 24 • Français 48 • Русский 72 • Deutsch 96

External

Power

Supply

Mounting

Hardware

(Y/N)

HDMI

Accessory

Cable

B127A-002-BH Y Y N

B127A-002-BHPH2 Y Y N

B127A-004-BH Y Y Y

B127A-004-BHPH3 Y Y Y

B127A-008-BH Y Y N

All

• Extend 4K audio and video signals up to 230 ft. away to an

HDMI display

• Support video resolutions up to 4K x 2K (3840 x 2160) @

60 Hz, as specied in HDMI 2.0, with 4:4:4 Chroma

Subsampling

• Carry High Dynamic Range (HDR) signals for expanded

color accuracy

• Comply with HDCP 2.2 standards

• Power over Cable (PoC) technology provides power from

splitter to connected receiver units over Cat6 cabling

• Plug and play – no software or drivers required

Package Contents

Product Features

B127A-002-BH

• Extends and splits a 4K audio/video signal with power to two

displays up to 230 ft. away over 24 AWG Cat6 cabling

• Compatible with Tripp Lite B127A-Series Receiver units such

as B127A-1A0-FH or B127A-1A0-BH (sold separately)

• Supports true uncompressed 7.1-channel digital audio and

Dolby TrueHD

• Multi-resolution support allows receiver units to be used

on any display that supports 1080p, 4K/30 Hz or 4K/60 Hz

without a󰀨ecting the video resolution of the other connected

receiver

• Power over Cable (PoC) technology provides power from the

splitter unit to the connected receivers via Cat6 cabling

• Included mounting hardware allows splitter unit to be wall-

mounted, rack-mounted or pole-mounted

B127A-002-BHPH2

• Extends and splits a 4K audio/video signal with power to two

displays up to 230 ft. away over 24 AWG Cat6 cabling

• Kit includes two pigtail receivers that each support 4K/60 Hz

video resolutions

• Compatible with Tripp Lite B127A-Series Receiver units such

as B127A-1A0-FH or B127A-1A0-BH (sold separately)

• Supports true uncompressed 7.1-channel digital audio and

Dolby TrueHD

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Splitter
Modell:	B127A-008-BH
Bredde:	440 mm
Dybde:	181 mm
Høyde:	44 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	2600 g
Sertifisering:	CCC; CE; FCC; GS; TUV; UL; cUL, UL Listed; cUL Listed, RoHS; CE (Europe); REACH; FCC (USA)
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
3D:	Ja
HDMI-versjon:	2.0
Antall per pakke:	1 stykker
Fargedybde:	36 bit
Utgangsstrøm:	24 V
HDCP-versjon:	2.2
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Antall videoporter:	8
Kabellengde:	1.5 m
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Pakkebredde:	290.1 mm
Kabler inkludert:	DC
Pakketype:	Boks
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	8
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	CCC, CE, Federal Communications Commission (FCC), REACH, RoHS, UL ECOLOGO, WEEE
Harmonisert system (HS)-kode:	8525.50.3035
Kroppsmateriale:	Metall
Video ut:	8x RJ-45
DC-inngangskontakt:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Plugg inn og spill:	Ja
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) bruttovekt:	3600 g
Masterkassens (ytterkassens) lengde:	310.9 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	517.9 mm
Masterkassens (ytterkassens) høyde:	178.1 mm
Kabeltyper som støttes:	Cat6
Maksimal opereringsrekkevidde:	70.1 m
Video tilkoblingstype:	HDMI
Consumer Electronics Control (CEC)-støtte:	Ja
