Side 1/36

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

Owner’s Manual

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

DisplayPort / Mini DisplayPort

v1.2 Multi-Stream

Transport Hubs

Models: (DisplayPort Out) B155-002-DP-V2,

B155-003-DP-V2, B155-004-DP-V2,

B156-002-V2, B156-003-V2, B156-004-V2

(DVI Out) B155-002-DVI-V2, B156-002-DVI-V2

(HDMI Out) B155-002-HD-V2, B155-003-HD-V2,

B155-004-HD-V2, B156-002-HD-V2,

B156-003-HD-V2, B156-004-HD-V2

Español 13 • Français 25

20-11-191-933D83.indd 120-11-191-933D83.indd 1 7/30/2021 11:12:43 AM7/30/2021 11:12:43 AM

Product Features

• Connect multiple monitors via the DisplayPort

or Mini DisplayPort output on your computer to

display the same image on each monitor, extend

the desktop across monitors, or combine as one

enlarged monitor in video wall mode.*

• DisplayPort v1.2 and Multi-Stream Transfer (MST)

compliant.*

• Built-in cable connects directly to a DisplayPort or

Mini DisplayPort source.

• DisplayPort and HDMI output models support

4K x 2K Ultra High Deﬁnition (UHD)

resolutions

up to 3840 x 2160 (60 Hz) – see System

Requirements for more information.

• DVI output models support video resolutions up to

1920 x 1080 (60Hz) – see System Requirements

for more information.

• 2-port models are powered via USB Micro-B—

no external power supplies required.

•

Supports up to 48-bit Deep Color (16 bits per channel).

20-11-191-933D83.indd 220-11-191-933D83.indd 2 7/30/2021 11:12:43 AM7/30/2021 11:12:43 AM

Product Features

• Supports DTS-HD, Dolby True HD and 7.1 channel

surround sound audio.

• Supports HDCP, EDID and DDC.

• Compliant with the Federal Trade Agreements Act

(TAA) for GSA Schedule purchases.

* Backward compatible with most DisplayPort 1.1a equipment

running current graphics drivers. The feature set is limited

to the attached equipment’s capabilities (e.g. you may

be limited to displaying in Clone / Mirror mode only).

Compatibility with older graphics cards is not guaranteed.

20-11-191-933D83.indd 320-11-191-933D83.indd 3 7/30/2021 11:12:43 AM7/30/2021 11:12:43 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Splitter
Modell:	B156-002-V2
Vekt:	90 g
Tilkobling:	DISPLAYPORT (MALE), (2) DISPLAYPORT (FEMALE)
Bruksanvisning:	Ja
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	180 g
Sertifisering:	CE, FCC, RoHS, REACH
Full HD:	Ja
HDCP:	Ja
Fargedybde:	48 bit
Dimensjoner (B x D x H):	76.2 x 25.4 x 61.5 mm
Støttede lydkanaler:	7.1
Antall videoporter:	2
Dolby-teknologier:	DTS-HD, Dolby TrueHD
Kabellengde:	0.15 m
Produktfarge:	Sort
Pakkedybde:	142 mm
Pakkehøyde:	199.9 mm
Pakkebredde:	43.9 mm
Kabler inkludert:	Micro-USB
Harmonisert system (HS)-kode:	8525.50.3035
Video ut:	2x DisplayPort
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332193367
Masterkassens (ytterkassens) bruttovekt:	2150 g
Masterkassens (ytterkassens) lengde:	213.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	152.9 mm
Masterkassens (ytterkassens) høyde:	455.9 mm
Enkel installering:	Ja
Video tilkoblingstype:	DisplayPort
HD-Ready:	Ja
