Owner’s Manual

Secure KVM Switches,

NIAP Protection Prole

Version 3.0

DisplayPort Models:

B002A-DP2A2, B002A-DP2AC2, B002A-DP1AC8

HDMI Models:

B002A-UH2A2, B002A-UH2AC2, B002A-UH2A4, B002A-UH2AC4

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 13 • Français 25

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Package Contents 3

Optional Accessories 3

System Requirements 3

Product Features 4

Important Safety 4

Instructions

Installation 6

KVM LEDs 7

Port Selection LEDs 7

Push-Button LEDs 7

Port Selection and 7

Push-Button LEDs

Console Video Port LED 7

Console CAC Port LED 7

EDID Learn 8

Miscellaneous KVM 9

Functionality

Disabling CAC Functionality 9

Enabling CAC Functionality 9

CAC Port Conguration 9

Auditing: Dumping the 10

Event Log

Reset: Restoring 11

Factory Defaults

Power-Up Self-Test 12

Warranty and 12

Product Registration

Table of Contents

Package Contents

Optional Accessories

System Requirements

• B002-Series Secure KVM Switch

• 12V 3A External Power Supply

• Owner’s Manual

• P312-Series 3.5 mm Stereo Audio Cables

• P569-XXX-CERT Premium High-Speed HDMI Cables

• P782-XXX-XXX HDMI/USB KVM Cable Kit

• P782-XXX-DH HDMI/DVI/USB KVM Cable Kit

• P783-XXX-XXX DisplayPort KVM Cable Kit

• P580-Series DisplayPort Cables

• U022-Series USB 2.0 A/B Device Cables

*XXX refers to length (e.g. 006 = 6 ft., 010 = 10 ft., and so on)

• DisplayPort, DVI* or HDMI monitor

• Wired USB mouse/keyboard without internal hub or composite device functions**

• Computer with DisplayPort, DVI* or HDMI port

• Computer with available USB port (USB 2.0 required for Common Access Card [CAC] support)

• Computer with available 3.5 mm stereo audio port

• Speakers with 3.5 mm stereo audio port

• Any major operating system, including Windows

and macOS

*Requires an HDMI to DVI adapter, such as Tripp Lite’s P130-000

**Wireless keyboard and mouse are not supported

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B002A-DP2AC2
Innebygd skjerm:	Nei
Vekt:	1360 g
Bredde:	319.3 mm
Dybde:	170.2 mm
Høyde:	68.6 mm
Strømkilde:	DC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A, USB Type-B
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	USA
Pakkevekt:	1810 g
Hodetelefonutganger:	2
HDCP:	Ja
Antall DisplayPorts:	6
Antall brukere:	1 bruker(e)
Utgangsstrøm:	12 V
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	2
Lydtilkoblinger:	Ja
Kabellengde:	1.5 m
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	108 mm
Pakkehøyde:	317.5 mm
Pakkebredde:	241.3 mm
Kabler inkludert:	AC
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	0 - 80
Harmonisert system (HS)-kode:	8471.80.4000
Kroppsmateriale:	Metall
Ekstern strømadapter:	Ja
DC-inngangskontakt:	Ja
Støttede Windows operativsystemer:	Ja
Antall USB 2.0 Type-B-porter:	4
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Nei
AC-adapter bunt:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332261530
Masterkassens (ytterkassens) bruttovekt:	20410 g
Masterkassens (ytterkassens) lengde:	482.6 mm
Produkter per masterkasse (ytterkasse):	12 stykker
Masterkassens (ytterkassens) bredde:	482.6 mm
Masterkassens (ytterkassens) høyde:	635 mm
Innput-strøm:	0.8 A
Video tilkoblingstype:	DisplayPort
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
Konsoll porter:	3.5mm headphone, DisplayPort, USB A
Antall konsoll USB porter:	3
Trykk på knapp:	Ja
