Side 1/72

Owner’s Manual

Dual Display DVI/USB

KVM Switch with Audio and

Peripheral Sharing

Models: B004-2DUA2-K, B004-2DUA4-K

Package Contents 2

System Requirements 3

Features 4

Safety Instructions 7

Installation 9

Basic Operation 13

Firmware Upgrade 21

Factory Default Settings 22

Speciﬁcations 23

Warranty and Product Registration 24

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 25 • Français 49

Package Contents

• B004-2DUA2-K or B004-2DUA4-K KVM Switch

• (x2) 6 ft. USB KVM Cable Kits (B004-2DUA2-K only)

• (x2) 6 ft. DVI-D Dual Link Cables (B004-2DUA2-K only)

• (x4) 6 ft. USB KVM Cable Kits (B004-2DUA4-K only)

• (x4) 6 ft. DVI-D Dual Link Cables (B004-2DUA4-K only)

• External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5.3V, 2.4A)

• Rackmount Hardware (B004-2DUA4-K only)

• Owner’s Manual

Optional Accessories:

• P312-Series Mini Stereo Audio Cables

• P556-Series DVI to VGA Adapter Cables

• P560-Series DVI-D Dual Link Cables

• P561-Series DVI-D Single Link Cables

• P759-Series DVI/USB + Audio KVM Cable Kits

• U022-Series USB 2.0 A/B Device Cables

System Requirements

Console:

• Two DVI or VGA* monitors capable of supporting the highest resolution out of any

computer in the installation

• USB keyboard and mouse

• Microphone and speakers with 3.5 mm Mini Stereo connectors (If using the

microphone and speakers audio feature)

*Requires an adapter, such as Tripp Lite’s P556-Series DVI to VGA adapter cables

Computer:

• (x2) DVI or VGA* ports

• (x4) DVI or VGA* ports (for Quad-View Mode**)

• A USB port

• 3.5 mm Mini Stereo microphone and speaker jacks (If using the microphone and

speakers audio feature)

*Requires an adapter, such as Tripp Lite’s P556-Series DVI to VGA adapter cables. Note that

the included DVI cables and cable kits are DVI-D only, and cannot be converted to VGA using an

adapter.

**See the Quad-View Mode section of this manual for details

Supported Operating Systems:

OS Version

Windows 2000 and higher

Mac OS 9.0 and higher

Linux Kernel 2.6 and higher

Linux RedHat 9.0 and higher

Linux Fedora Core 4 and higher

Linux SuSE 9.0 and higher

OS Version

UNIX AIX 4.3 and higher

UNIX FreeBSD 4.2 and higher

UNIX Sun Solaris 9 and higher

Novell Netware 6.0 and higher

DOS 6.22 and higher

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B004-2DUA2-K
Innebygd skjerm:	Ja
Vekt:	560 g
Bredde:	260.4 mm
Dybde:	76.2 mm
Høyde:	44.4 mm
Bruksanvisning:	Ja
Maksimal oppløsning:	2560 x 1600 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	2310 g
Antall USB 2.0-porter:	6
Hodetelefonutganger:	4
Utgangsstrøm:	2.4 A
AC-inngangsfrekvens:	50 - 60 Hz
Antall mikrofoninnganger:	4
Antall datamaskiner:	2
Lydtilkoblinger:	Ja
Produktfarge:	Sort
Pakkedybde:	215.9 mm
Pakkehøyde:	101.6 mm
Pakkebredde:	323.8 mm
Kabler inkludert:	DC, DVI
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Harmonisert system (HS)-kode:	8471.80.1000
DC-inngangskontakt:	Ja
Antall DVI-I-porter:	6
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
AC-adapter bunt:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332180329
Masterkassens (ytterkassens) bruttovekt:	11480 g
Masterkassens (ytterkassens) lengde:	342.9 mm
Produkter per masterkasse (ytterkasse):	5 stykker
Masterkassens (ytterkassens) bredde:	513.1 mm
Masterkassens (ytterkassens) høyde:	231.1 mm
Innput-strøm:	0.5 A
Video tilkoblingstype:	DVI-D
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
