Side 1/8

Owner’s Manual

DVI/USB + Audio &

Peripheral Sharing

KVM Switch

Model: B043-DUA8-SL

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Table of Contents

Package Contents 2

Optional Accessories 2

System Requirements 2

Product Features 2

Front Panel 3

Safety Instructions 4

Rackmount Installation 5

System Installation 5

Operation 6

Warranty & Warranty Registration 8

14-03-102-933345.indd 1 4/2/2014 10:43:32 AM

Package Contents

Optional Accessories

System Requirements

Product Features

• B043-DUA8-SLKVMSwitch

• ExternalPowerSupply(Input:100-240V,50/60Hz;Output:9V,2A)

• RackmountHardware

•Owner’sManual

• P312-Series3.5mmMiniStereoAudioCables

• P556-SeriesDVIMaletoVGAMaleAdapterCables

• P561-006-SLIDVI-ISingle-LinkDigital/AnalogCable–6ft.

• P561-SeriesDVI-DSingle-LinkCables

• P759-SeriesDVI-D/USB/AudioKVMCableKits

• U022-SeriesUSB2.0A/BDeviceCables

• UR022-SeriesReversibleUSB2.0A/BDeviceCables

• DVIorVGA*monitor

• USBmouseandkeyboard

• ComputerwithaDVIorVGA*port

• ComputerwithaUSBport

• P759-SeriesDVI-D/USB/AudioKVMcablekitforeachconnectedcomputer

• Microphonewitha3.5mmMaleconnector(ifusingthemicrophonefeature)

• Speakerswitha3.5mmMaleconnector(ifusingthespeakerfeature)

• Compatiblewithallmajoroperatingsystems

*Requires a DVI to VGA adapter

• Directlyconnectupto8computerswithDVI,USB,andaudio.

• ExpandthenumberofconnectedcomputersbycascadinganadditionallevelofKVMswitches.

• Supports2.1ChannelStereoAudioandmicrophone.

• (x2)USB2.0portsforsharingperipheralsamongconnectedcomputers.

• USBhubfunctionalitycanbeunbindedfromtheKVM,allowinguserstoaccessonecomputer

whiletheUSBhubfocusremainsonanothercomputer.

• Switchbetweenconnectedcomputersviapushbuttonsorhotkeycommands.

• DVI-ISingle-Linksupportsdigitalvideoresolutionsupto1920x1200,andanalogvideo

resolutionsupto2048x1536.

• AutoScanmodeletsusersscanconnectedcomputerswithouthavingtomanuallyswitch

betweenthem.

• Multi-platformsupport–compatiblewithallmajoroperatingsystems.

• Plugandplaysetup–nosoftwareinstallationrequired.

• SupportsEDID(ExtendedDisplayIdenticationData)transmissiontoconnectedcomputersfor

optimaldisplayperformance.

• Includesmountinghardwarefor19”rackmountinstallations.

14-03-102-933345.indd 2 4/2/2014 10:43:32 AM

Front Panel

USB 2.0 Hub Ports–TwohubportsallowforUSBperipheralsharingamongconnected

computers.

BANK LED–This2-digitdisplayrepresentstheKVM’splaceinacascadedinstallationhierarchy.

TherstKVMinachainwillhaveaBANKnumberof00;standaloneKVM’swillalsohavea

BANKnumberof00.AKVMthatiscascadedtothePC1portswillhaveaBANKnumberof01,

aKVMcascadedtothePC2portswillhaveaBANKnumberof02,andsoon.

Port Selection Pushbuttons –PressapushbuttontobringthefocusoftheKVM,Audioand

USBhubtothecorrespondingport.Note: The USB Hub focus can be unbinded from the KVM

via keyboard hotkey. See the Operation section for details.

Power Jack –TheincludedpowersupplyconnectstotheKVMswitchhere.

Console Ports–Yourmonitor,keyboard,mouse,microphoneandspeakersplugintothese

ports.

Computer Ports –ConnecteachsetofcomputerportstoacomputerusingaP759-Series

DVI-D/USB/AudioKVMcablekit.

4 5 6

2 3

14-03-102-933345.indd 3 4/2/2014 10:43:32 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	NetController B043-DUA8-SL
Innebygd skjerm:	Nei
Vekt:	1500 g
Bredde:	406.4 mm
Dybde:	101.6 mm
Høyde:	44.4 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Maksimal oppløsning:	1920 x 1200 piksler
Opprinnelsesland:	China
Pakkevekt:	2220 g
Sertifisering:	FCC
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	8
Lydtilkoblinger:	Ja
Produktfarge:	Sort
Pakkedybde:	292.1 mm
Pakkehøyde:	71.1 mm
Pakkebredde:	439.4 mm
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Harmonisert system (HS)-kode:	8517.62.0020
Rack-kapasitet:	1U
Rack-montering:	Ja
AC-adapter bunt:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332182392
Masterkassens (ytterkassens) bruttovekt:	12380 g
Masterkassens (ytterkassens) lengde:	391.2 mm
Produkter per masterkasse (ytterkasse):	5 stykker
Masterkassens (ytterkassens) bredde:	464.8 mm
Masterkassens (ytterkassens) høyde:	320 mm
Video tilkoblingstype:	DVI-I
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
