Side 1/8

Owner’s Manual

DisplayPort KVM Switch

with Audio and SuperSpeed

USB 3.0 Hub

Models: B004-DPUA2-K, B004-DPUA4-K

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Table of Contents

Package Contents 2

Optional Accessories 2

System Requirements 2

Features 3

Installation 4

Operation 5

Warranty and 7

Product Registration

15-05-047-933455.indd 1 5/7/2015 4:20:53 PM

Package Contents

Optional Accessories

System Requirements

B004-DPUA2-K

• (x2) DisplayPort Cables – 4 ft.

• (x2) USB 3.0 A/B Cables – 4 ft.

• (x2) 3.5 mm Mini-Stereo Speaker/

Microphone Cables – 4 ft.

• External Power Supply

(Input: 100/240V, 50/60Hz, 0.5A;

Output: 9V, 2A)

• Owner’s Manual

B004-DPUA4-K

• (x4) DisplayPort Cables – 6 ft.

• (x4) USB 3.0 A/B Cables – 6 ft.

• (x4) 3.5 mm Mini-Stereo Speaker/

Microphone Cables – 6 ft.

• External Power Supply

(Input: 100/240V, 50/60Hz, 0.5A;

Output: 9V, 2A)

• Owner’s Manual

• P579-006 DisplayPort Extension Cable (M/F) – 6 ft.

• P580-Series DisplayPort Cables (M/M)

• U322-Series USB 3.0 A/B Cables (M/M)

• U324-Series USB 3.0 A/A Extension Cables (M/F)

• U326-Series USB 3.0 Micro-B/A Cables (M/M)

• DisplayPort monitor

• Computer with an available USB 3.0 port (a USB 2.0 or 1.1 port can be used,

but it will not achieve USB 3.0 speeds)

• USB keyboard and mouse

• Speaker and microphone with 3.5 mm mini-stereo jacks

(if using the audio feature)

• Computer with 3.5 mm mini-stereo speaker and microphone jacks

(if using the audio feature)

• OS-independent; compatible with all major operating systems

15-05-047-933455.indd 2 5/7/2015 4:20:53 PM

Features

• Control two or four DisplayPort computers with a single DisplayPort monitor, USB

keyboard and USB mouse

• DisplayPort, USB 3.0, and audio cabling included

• Switch ports via pushbutton or keyboard hotkey commands

• Auto Scan feature automatically switches between connected computers at

regular intervals

• 3.5 mm mini-stereo speaker and microphone connections allow sharing of audio

equipment between systems

• Supports 2-channel stereo audio

• Audio can be switched independently, allowing music to play from one computer

while you access another computer

• Features two SuperSpeed USB 3.0 hub ports for sharing peripherals between

connected computers

• Supports USB 3.0 data transfer rates up to 5 Gbps; backward compatible with

USB 2.0 and 1.1 devices

• USB hub functionality can be switched independently, allowing you access to one

computer while the USB hub ports remain connected to another computer

• Advanced emulation technology ensures compatibility with USB keyboards and

mice, and provides super-fast port switching

• Supports digital video resolutions up to 2560 x 1600

• DDC emulation sends the monitor’s EDID information to connected computers to

ensure optimal video quality

15-05-047-933455.indd 3 5/7/2015 4:20:53 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B004-DPUA4-K
Innebygd skjerm:	Nei
Vekt:	950 g
Bredde:	205.7 mm
Dybde:	99.1 mm
Høyde:	45.7 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A, USB Type-B
Maksimal oppløsning:	2560 x 1600 piksler
Opprinnelsesland:	China
Pakkevekt:	2680 g
Antall USB 2.0-porter:	2
Hodetelefonutganger:	4
USB-versjon:	2.0/3.2 Gen 1 (3.1 Gen 1)
Antall brukere:	1 bruker(e)
USB-hub:	Ja
Utgangsstrøm:	9 V
AC-inngangsfrekvens:	50 - 60 Hz
Antall mikrofoninnganger:	4
Antall datamaskiner:	4
Lydtilkoblinger:	Ja
Kabellengde:	1.8 m
Produktfarge:	Sort
Pakkedybde:	269.2 mm
Pakkehøyde:	188 mm
Pakkebredde:	157.5 mm
Kabler inkludert:	Audio (3.5mm), DisplayPort, USB
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8517.62.0020
DC-inngangskontakt:	Ja
Støttede Windows operativsystemer:	Ja
Rack-montering:	Nei
AC-adapter bunt:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332188639
Masterkassens (ytterkassens) bruttovekt:	17010 g
Masterkassens (ytterkassens) lengde:	551.2 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	492.8 mm
Masterkassens (ytterkassens) høyde:	215.9 mm
Innput-strøm:	0.8 A
Video tilkoblingstype:	DisplayPort
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
Konsoll porter:	3.5mm headphone, 3.5mm mic, DisplayPort, USB B
Antall konsoll USB porter:	4
Displaytilkobling:	Ja
DDC/DDC2 støttet:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports:	2
