Owner’s Manual

1U Rackmount Console

(for KVM Switch or Server)

Models:

B021-000-17 & B021-000-19

Series No:

AGCB6533

1111 West 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.

Package Contents

Overview

Tripp Lite's 1U Rackmount Console features an integrated LCD monitor, full keyboard and touch pad in a 1U rackmountable housing. This console is

designed for use with a server or a KVM switch with PS/2 console connectors. A PS/2 to USB adapter is included to connect to a USB KVM or server.

Features

• Rackmount console (LCD monitor, keyboard, touch pad) in an integrated 1U rackmountable housing

• Sleep mode when the monitor cover is closed

• Rackmountable in standard 19-inch rack (1U)

• Includes rackmount brackets

• Supports resolutions up to 1366 x 768 pixels

• Includes a USB 2.0 Pass-Through port which can be used to provide easy access to a USB port on a connected device (KVM switch or

computer)

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during the installation and operation of the rackmount console

described in this manual. Read all instructions thoroughly before attempting to install or operate the rackmount console. Failure to comply

will void the warranty and could damage the rackmount console or connected equipment.

WARNING:

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the

life support equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence

of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

Español 5 • Français 9

• Русский 13

• 1U Rackmount Console

• KVM Cable Kit (VGA, PS/2)

• PS/2 to USB Adapter

• AC Power Cord

• Owner’s Manual

• Mounting Brackets

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B021-000-17
Vekt:	12600 g
Bredde:	449.3 mm
Dybde:	722.4 mm
Høyde:	43.4 mm
AC-adapter inngangsspenning:	120 - 240 V
Opprinnelsesland:	Taiwan
Pakkevekt:	17960 g
Sertifisering:	UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, IEC 60950-1
On Screen Display (OSD):	Ja
Størrelse:	19 "
Skjermoppløsning:	1366 x 768 piksler
Pakkedybde:	823 mm
Pakkehøyde:	157.5 mm
Pakkebredde:	596.9 mm
Skjermdiagonal:	17 "
Bærekraftsertifikater:	RoHS
I/O-porter:	HD15 (x1)\r\nMiniDIN6 (x2)
Videoopptaksgrensesnitt:	HD15, VGA, USB, PS/2
Display:	LCD
Masterkassens (ytterkassens) bruttovekt:	17960 g
Masterkassens (ytterkassens) lengde:	823 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	596.9 mm
Masterkassens (ytterkassens) høyde:	157.5 mm
Høyde (i stabelenheter):	1
