Les nedenfor 📖 manual på norsk for Tripp Lite B021-000-19-HD (12 sider) i kategorien Bryter. Denne guiden var nyttig for 9 personer og ble vurdert med 4.3 stjerner i gjennomsnitt av 5 brukere

Last ned PDF

Side 1/12

Owner’s Manual

1U Rackmount Console

(for KVM Switch or Server)

Model:

B021-000-19-HD

Series No:

AGCB6533

1111 West 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Package Contents

Features

• Rackmount console (LCD monitor, keyboard, touch pad) in an integrated 1U rackmountable housing

• Sleep mode when the monitor cover is closed

• Rackmountable in standard 19-inch rack (1U)

• Includes rackmount brackets

• Supports resolutions up to 1366 x 768 pixels

• Includes a USB 2.0 Pass-Through port which can be used to provide easy access to a USB port on a connected device

(KVM switch or computer)

• Includes a DVI-I port for connecting to a DVI or VGA* server or KVM switch

*VGA server connection using the included DVI-to-VGA adapter

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during the installation and operation of the rackmount console

described in this manual. Read all instructions thoroughly before attempting to install or operate the rackmount console. Failure to comply

will void the warranty and could damage the rackmount console or connected equipment.

WARNING:

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the

life support equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence

of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

Español p. 5 Français p. 9

• 1U Rackmount Console

• KVM Cable Kit (DVI-I, USB)

• DVI (Female) to VGA (Male) Adapter

• AC Power Cord

• Owner’s Manual

• Mounting Brackets

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $50 value!

www.tripplite.com/warranty

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B021-000-19-HD
Vekt:	12600 g
Bredde:	477 mm
Dybde:	692.4 mm
Høyde:	43.2 mm
Bruksanvisning:	Ja
AC-adapter inngangsspenning:	100 - 240 V
Opprinnelsesland:	Taiwan
Pakkevekt:	18010 g
Sertifisering:	UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, IEC 60950-1
Konsollport:	VGA
Strømforbruk (standby):	5 W
Produktfarge:	Sort
Pakkedybde:	828 mm
Pakkehøyde:	160 mm
Pakkebredde:	596.9 mm
Skjermtype:	LCD
Skjermdiagonal:	19 "
Kabler inkludert:	AC, KVM
Strømforbruk (vanlig bruk):	30 W
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-25 - 60 °C
Bærekraftsertifikater:	RoHS
Rack-kapasitet:	1U
Monteringsbeslag inkludert:	Ja
Masterkassens (ytterkassens) bruttovekt:	18010 g
Masterkassens (ytterkassens) lengde:	828 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	596.9 mm
Masterkassens (ytterkassens) høyde:	160 mm
Innput-strøm:	0.7 - 1.2 A
Luftfuktighetsområde ved drift:	20 - 90
AC-adapter frekvens:	50/60 Hz
