Owner’s Manual

DVI/USB Rack-mount

KVM Switch with Audio

and Peripheral Sharing

Models: B024-DUA8-SL (Single-Link),

B024-DUA8-DL (Dual-Link)

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Package Contents 2

Optional Accessories 2

System Requirements 2

Features 3

Safety Instructions 7

Installation 9

Basic Operation 17

Speciﬁcations 39

Warranty and 40

Product Registration

Regulatory Compliance 40

Español 41

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

17-10-479-93370A.indb 1 11/17/2017 2:28:56 PM

Package Contents

Optional Accessories

System Requirements

• B024-DUA8-SL or B024-DUA8-DL KVM Switch

• (x2) DVI/USB KVM Cable Kits, 6 ft.

• External Power Supply

B024-DUA8-SL – 1-15P Plug with 5 ft. Cord

(Input: 100-240V, 50/60 Hz, 0.5A; Output: 5.3V 2.4A)

B024-DUA8-DL – 1-15P Plug with 5 ft. Cord

(Input: 100-240V, 50/60 Hz, 0.7A; Output: 5.2V 4A)

• RJ11 to DB9 Firmware Upgrade Cable, 6 ft.

• Grounding Wire

• Rackmount Hardware

• Rubber Feet

• Owner’s Manual

• P312-Series 3.5 mm Stereo Audio Cables

• P502-Series High-Resolution VGA Monitor Cables

• P556-Series DVI to VGA Adapter Cables

• P560-Series DVI-D Dual Link Cables

• P561-Series DVI-D Single Link Cables

• P759-Series DVI/USB + Audio KVM Cable Kits

• U022-Series USB 2.0 A/B Device Cables

Console Requirements

• DVI or VGA (optional) monitor capable of supporting the highest resolution in the

installation

• USB keyboard and mouse

• Microphone and speakers with 3.5 mm connectors (optional)

Computer Requirements

• DVI* or VGA (optional) ports

• A USB port

• Microphone and speaker jacks with 3.5 mm connectors (optional)

*DVI dual-link ports required to obtain DVI dual-link video resolutions.

17-10-479-93370A.indb 2 11/17/2017 2:28:56 PM

System Requirements

Features

• 8-Port DVI/USB rack-mount KVM switch with audio and USB 2.0 peripheral sharing

• Connect up to 512 computers by cascading up to three levels of KVM switches

• Multi-view installation feature allows stacking of up to four KVMs for connecting

computers with up to four DVI output ports and displaying video on up to four

console monitors

• Built-in 2-port USB 2.0 hub allows USB devices to be shared among computers

connected to the KVM switch

• 3.5 mm microphone jack provides audio input to connected computers

• 3.5 mm audio jack provides rich 2.1 channel sound with full bass response to a set

of speakers via the computer’s audio output

• Additional console audio jacks are conveniently located on the front panel of the

KVM switch, ideal for use with IP phones

• The KVM and USB focus can be switched independently of one other; for example,

you can access one computer while simultaneously printing from another computer

• Switch between connected computers via front panel pushbuttons, keyboard

hotkeys, and the on-screen display (OSD)

• Multilingual OSD supports English, German, Japanese, Traditional Chinese,

Simpliﬁed Chinese, Spanish, Russian and French

• Auto Scan mode scans connected computers without manually switching between

them

• Broadcast mode simultaneously sends console commands to all computers to

perform operations

Supported Operating Systems

OS Version

Windows™ 2000 and higher

Mac

OS 9.0 and higher

Linux

Kernel 2.6 and higher

Linux RedHat 9.0 and higher

Linux Debian 3.1 / 4.0

Linux SuSE 10 / 11.1 and higher

Linux Ubuntu 7.04 / 7.10

UNIX AIX 4.3 and higher

UNIX FreeBSD 5.5 and higher

UNIX Sun Solaris 8 and higher

Novell Netware 6.0 and higher

17-10-479-93370A.indb 3 11/17/2017 2:28:56 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B024-DUA8-DL
Innebygd skjerm:	Nei
Vekt:	2810 g
Bredde:	436.9 mm
Dybde:	160 mm
Høyde:	43.9 mm
Strømkilde:	AC
LED-indikatorer:	Ja
Maksimal oppløsning:	2560 x 1600 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	3630 g
Antall USB 2.0-porter:	1
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	512
Lydtilkoblinger:	Ja
Automatisk veksling:	Ja
Kabellengde:	1.5 m
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	232.9 mm
Pakkehøyde:	116.1 mm
Pakkebredde:	540 mm
Strømforbruk (vanlig bruk):	6.36 W
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Harmonisert system (HS)-kode:	8471.80.1000
Kroppsmateriale:	Metall
Ekstern strømadapter:	Ja
Antall DVI-I-porter:	8
Rack-kapasitet:	1U
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Ja
AC-adapter bunt:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332205121
Masterkassens (ytterkassens) bruttovekt:	10890 g
Masterkassens (ytterkassens) lengde:	374.9 mm
Produkter per masterkasse (ytterkasse):	3 stykker
Masterkassens (ytterkassens) bredde:	564.9 mm
Masterkassens (ytterkassens) høyde:	258.1 mm
Innput-strøm:	2.4 A
Video tilkoblingstype:	DVI-I
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	PS/2
