Side 1/32

Owner’s Manual

2-Port USB/DP Cable

KVM Switch with Audio

Model: B032-DPUA2

Español 8 • Français 16 • Русский 24

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

18-10-178-933895.indb 1 10/23/2018 1:49:33 PM

Product Features

Optional Accessories

Package Contents

• Control two computers or devices from a single USB keyboard, mouse

and DisplayPort monitor

• Compact design features built-in 4 ft. KVM and audio cables

• USB mouse port can be used to connect a USB 1.1 hub for peripheral

sharing

• Supports 4K x 2K video resolutions up to 4096 x 2160 @ 30 Hz

• Features Remote Port Switching

• Supports Windows

, Mac

, and Linux

• No external power required

• HDCP compatible

• P580-Series DisplayPort Cables with Latches

• U222-004-R 4-Port USB 2.0 Hub

• U222-007-R 7-Port USB 2.0 Hub

• U222-010-R 10-Port USB 2.0 Hub

• U022-Series USB 2.0 A/B Device Cables

• U030-Series USB 2.0 Mini-B Cables

• U050-Series USB 2.0 Micro-B Cables

• B032-DPUA2

• Owner’s Manual

18-10-178-933895.indb 2 10/23/2018 1:49:33 PM

System Requirements

• DisplayPort monitor

• USB Keyboard

• USB Mouse

• Computer with a DisplayPort and USB port

Installation

Note: Make sure the power to all devices is turned off prior to installation. You must

unplug the power cords of any computers that have the Keyboard Power On function.

1. Plug your USB keyboard, mouse and DisplayPort monitor into the console

ports on the unit.

2. (Optional) A USB hub can be connected to the USB console mouse port,

allowing you to add multiple USB peripherals to your installation.

Note: To ensure proper functionality, use a hub with an external power supply. The

USB console mouse port supports USB 1.1 speeds.

3. (Optional) Plug your speakers and/or microphone into the audio jacks on

the side of the unit.

4. Plug the connectors of the built-in cables into their respective ports on

the computers you are installing.

5. Power on your devices.

Note: The unit’s power on default is to link to the ﬁrst computer that is powered on.

18-10-178-933895.indb 3 10/23/2018 1:49:33 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B032-DPUA2
Innebygd skjerm:	Nei
Vekt:	350 g
Bredde:	84.1 mm
Dybde:	83.3 mm
Høyde:	30.5 mm
Strømkilde:	DC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Maksimal oppløsning:	4096 x 2160 piksler
Opprinnelsesland:	China
Pakkevekt:	680 g
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
Antall brukere:	1 bruker(e)
DisplayPort-versjon:	1.1
Antall datamaskiner:	2
Kabellengde:	1.2 m
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	175 mm
Pakkehøyde:	63.5 mm
Pakkebredde:	239 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85176200
USB-strøm:	Ja
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Nei
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332235975
Masterkassens (ytterkassens) bruttovekt:	5810 g
Masterkassens (ytterkassens) lengde:	327.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	497.1 mm
Masterkassens (ytterkassens) høyde:	198.1 mm
Video tilkoblingstype:	DisplayPort
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
Kablet fjernbryter:	Nei
