Tripp Lite B032-HUA2 Bruksanvisning

Tripp Lite Bryter B032-HUA2

Les nedenfor 📖 manual på norsk for Tripp Lite B032-HUA2 (52 sider) i kategorien Bryter. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/52

Owner’s Manual

2-Port USB/HD Cable

KVM Switch with Audio

Model: B032-HUA2

Español 14 • Français 27 • Русский 40

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

16-11-116-93366A.indb 1 12/15/2016 10:43:24 AM

Product Features

• Control two computers or devices from a single USB keyboard, mouse

and HDMI monitor

• Compact design features built-in 4 ft. KVM and audio cables

• The KVM and audio can be switched independently of each other, so you

can access one computer while listening to audio from another at the

same time*

• Audio provides a full bass response for rich 2.1-channel surround sound

• USB mouse port can be used to connect a USB 2.0 hub for peripheral

sharing

• Supports video resolutions up to 1920 x 1200 (1080p)

• KVM stores the monitor’s EDID information to optimize display resolution

• Power on detection automatically switches to the powered-on computer

when the other one powers off

• Console mouse port emulation/bypass feature supports most mouse

drivers and multifunction mice

• Supports gaming keyboards and wireless keyboard/mouse

• Features Remote, Hotkey and Mouse Port Switching

• Supports Windows

, Mac

, and Linux

• Mac keyboard support and emulation**

• No external power required

• HDCP compatible

• Firmware upgradable

* Audio through the HDMI monitor’s built-in speakers cannot be switched independently

** PC keyboard combinations emulate Mac keyboards; Mac keyboards only work with

their own computers

16-11-116-93366A.indb 2 12/15/2016 10:43:24 AM

Optional Accessories

System Requirements

Package Contents

• P568-Series High Speed HDMI Cables

• U222-004-R 4-Port USB 2.0 Hub

• U222-007-R 7-Port USB 2.0 Hub

• U222-010-R 10-Port USB 2.0 Hub

• U022-Series USB 2.0 A/B Device Cables

• U030-Series USB 2.0 Mini-B Cables

• U050-Series USB 2.0 Micro-B Cables

• HDMI monitor

• USB Keyboard

• USB Mouse

• Computer with a HDMI and USB port

• B032-HUA2

• Owner’s Manual

16-11-116-93366A.indb 3 12/15/2016 10:43:24 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B032-HUA2
Innebygd skjerm:	Nei
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A
Maksimal oppløsning:	1920 x 1200 piksler
Opprinnelsesland:	China
Pakkevekt:	540 g
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
Antall brukere:	1 bruker(e)
Antall datamaskiner:	2
Lydtilkoblinger:	Ja
Kabellengde:	1.2 m
Produktfarge:	Sort
Pakkedybde:	238.8 mm
Pakkehøyde:	61 mm
Pakkebredde:	170.2 mm
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85176200
Hurtigtaster:	Ja
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Plugg inn og spill:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332200393
Masterkassens (ytterkassens) bruttovekt:	5990 g
Masterkassens (ytterkassens) lengde:	487.7 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	327.7 mm
Masterkassens (ytterkassens) høyde:	198.1 mm
Video tilkoblingstype:	HDMI
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
