Owner’s Manual

HDMI KVM over IP Remote

User Console Station

Model: B064-000-STN

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

1. Overview 4

1.1 Features 4

1.2 Package Contents 4

1.3 Optional Accessories 4

1.4 System Requirements 4

1.5 Introduction 5

2. Setup 6

2.1 Mounting Instructions 6

2.2 Installation 8

3. Operation 9

3.1 Logging In 9

3.2 Dashboard 10

3.3 Dashboard Operation 11

3.4 Tab/Panel Array Display 13

and Management

3.4.1 Tab Options 13

3.4.2 Panel Array Options 14

3.4.3 Tab/Panel Array 16

Management

3.4.4 Adding a Tab 17

3.4.5 Adding Another Tab 18

3.4.6 Editing a Tab 18

3.4.7 Deleting a Tab 18

4. Device Management 19

4.1 Device List 19

4.1.1 Search 20

4.1.2 Removing a Device 20

4.1.3 Adding a Device 20

4.1.4 Changing Connection 21

Information

5. System Conﬁguration 22

5.1 User Management 22

5.1.1 Users and Groups 22

5.1.1.1 Add User 23

5.1.1.2 Copy User 25

5.1.1.3 Modify User 25

5.1.1.4 Delete User 25

5.1.2 Managing (Assigning) 26

Users and Groups

5.1.2.1 Using User 26

Conﬁguration Page

5.1.2.2 Using Group 27

Conﬁguration Page

5.1.3 Device Assignment 28

5.1.3.1 Using Device 28

Conﬁguration Page

5.2 Device Management 30

5.2.1 Device Information 30

5.2.2 Network 31

5.2.2.1 IP Installer 32

5.2.2.2 IPv4 Settings 32

5.2.2.3 IPv6 Settings 32

5.2.2.4 Finishing Up 32

5.2.3 Advanced Network 33

Management Settings

(ANMS)

5.2.3.1 RADIUS Settings 34

5.2.3.2 AD/LDAP Settings 34

5.2.3.3 Finishing Up 35

5.2.4 Security 35

5.2.4.1 Login Failures 36

5.2.4.2 Account Policy 36

5.2.4.3 Working Mode 36

5.2.4.4 Finishing Up 36

Table of Contents

5.3 Maintenance 37

5.3.1 Upgrade Main Firmware 37

5.3.2 Firmware Upgrade 38

Recovery

5.3.3 Backup/Restore 38

5.3.3.1 Backup 39

5.3.3.2 Restore 40

5.3.4 Push/Pull Conﬁguration 41

5.3.4.1 Pull Conﬁguration 42

5.3.4.2 Push Conﬁguration 42

5.3.5 Terminal 43

5.3.6 System Operation 44

5.3.6.1 Reset Default 44

Values

5.3.6.2 Reset on Exit 44

5.4 Quick User Conﬁguration 45

6. Toolbar Interface 46

6.1 Exit Remote Location 47

6.2 Video Settings 48

6.3 Macros 49

6.3.1 Hotkeys 50

6.3.2 User Macros 51

6.3.3 Import/Export Macros 55

6.3.4 Delete Macros 55

6.3.5 Search Macros 56

6.3.6 System Macros 56

6.4 Further Conﬁguration 57

6.4.1 Virtual Media 58

6.4.2 Message Board 60

6.4.2.1 Buttons 60

6.4.2.2 Message Display 61

Panel

6.4.2.3 Compose Panel 61

6.4.2.4 User List Panel 61

6.4.3 Mouse Sync Mode 62

6.4.3.1 Automatic Mouse 62

Synchronization

6.4.3.2 Manual Mouse 62

Synchronization

6.4.3.3 Mac and Linux 62

Considerations

7. Speciﬁcations 63

8. Warranty and 64

Product Registration

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	B064-000-STN
Innebygd skjerm:	Nei
Vekt:	750 g
Maksimal oppløsning:	1920 x 1200 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	1400 g
Antall HDMI-porter:	1
Sertifisering:	CCC, CE, FCC, PSE, TUV, UL, cUL
Kablingsteknologi:	10/100/1000Base-T(X)
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	1
Kabellengde:	1.2 m
Produktfarge:	Sort
HD-type:	Full HD
Pakkedybde:	325.1 mm
Pakkehøyde:	210.1 mm
Pakkebredde:	98 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Harmonisert system (HS)-kode:	8471.80.1000
Kroppsmateriale:	Metall
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332252774
Masterkassens (ytterkassens) bruttovekt:	7910 g
Masterkassens (ytterkassens) lengde:	512.1 mm
Produkter per masterkasse (ytterkasse):	5 stykker
Masterkassens (ytterkassens) bredde:	231.9 mm
Masterkassens (ytterkassens) høyde:	341.9 mm
Innput-strøm:	0.7 A
Video tilkoblingstype:	HDMI
Tastatur tilkoblingstype:	USB
Mus tilkoblingstype:	USB
Konsoll porter:	HDMI, USB A
Antall konsoll USB porter:	4
