Owner’s Manual

NetCommander

Cat5 KVM Switch

Models: B070-008-19-IP, B070-016-19-IP, B072-008-1-IP, B072-016-1-IP

(Series Number: AG-00C3)

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

The policy of Tripp Lite is one of continuous improvement. Speciﬁcations are subject to change without notice.

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $50 value!

www.tripplite.com/warranty

14-03-051 93-32D5.indd 1 3/14/2014 9:52:16 AM

Table of Contents

Legal Notice............................3

1. Product Overview......................3

1.1 Features and Beneﬁts ........................3

1.2 Terminology ................................4

1.3 Target Server Compatibility ....................4

1.4 Client Computer Compatibility..................4

1.5 Safety ....................................4

1.6 System Components .........................5

1.7 The NetCommander IP Unit ....................6

1.8 Rackmounting the NetCommander IP ............8

1.8.1 Standard Console KVM Switch Instructions...........8

1.8.2 2-Post Rack Console KVM Switch Instructions ........8

1.9 Connecting the System .......................9

1.10 Initial Settings (Default IP Address) ............9

2. Web Conﬁguration Interface .............13

2.1 Logging Into the Web Conﬁguration Interface......13

2.2 Web Conﬁguration Interface Layout .............14

2.3 My Targets Section ..........................15

2.4 Conﬁguration Section ........................16

2.4.1 Firmware Upgrade ............................17

2.4.2 Backup/Restore ..............................19

2.4.3 SSL Certiﬁcate ..............................20

2.4.4 Device ....................................21

2.4.5 Users .....................................22

2.4.6 Switch Conﬁguration ..........................24

2.4.7 User Targets ................................25

2.4.8 Power Devices...............................25

2.4.9 Power Outlets ...............................27

2.4.10 Serial Ports ................................28

2.4.11 Security ..................................28

2.4.12 Authentication..............................30

2.4.13 Date & Time ...............................34

2.5 Password Section ...........................34

2.6 Events Section..............................35

3. Conducting a Remote Session............36

3.1 Starting a Remote Session ....................36

3.2 Remote Session Toolbar ......................37

3.2.1 Pin Toolbar .................................37

3.2.2 Session ...................................37

3.2.3 Video .....................................39

3.2.4 Power.....................................40

3.2.5 Keys......................................41

3.2.6 Mouse ....................................43

3.2.7 Server/Serial ................................46

3.2.8 Full Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

3.2.9 Logout ....................................46

3.3 Shared Session .............................46

3.4 Exclusive Session ...........................46

4. Local Console ........................47

4.1 Move Label (F1) .............................47

4.2 Tuning (F5) .................................47

4.3 Power Management ..........................48

4.4 (F2) Setting ................................48

5. Serial Port Pinout .....................51

6. Security Certiﬁcate Installation ..........51

7. Technical Speciﬁcations ................57

8. Video Resolution and Refresh Rates .......58

9. Warranty & Warranty Registration .........58

14-03-051 93-32D5.indd 2 3/14/2014 9:52:16 AM

Legal Notice

This manual and the software described in it are furnished under license, and may be used or copied only in accordance with the terms

of such license. The content of this manual is provided for informational use only, and is subject to change without notice. It should not in

and of itself be construed as a commitment by Tripp Lite, which assumes no responsibility of liability for any errors or inaccuracies that may

appear in this book.

The software that accompanies this manual is licensed for use by the Licensee only, in strict accordance with the software license

agreement, which the Licensee should read carefully before commencing use of the software. Except as permitted by the license, no part

of this publication may be reproduced, stored in retrieval system, or transmitted in any form or by any means, electronic, mechanical,

recording, or otherwise, without the prior written permission of Tripp Lite.

1. Product Overview

1.1 Features and Beneﬁts

•Directlyconnectupto16(B070-016-19-IPorB072-016-1-IP)or8(B070-008-19-IPorB072-008-1-IP)computers/servers.

•Upto2users(1local,1remote)cansimultaneouslyaccesstheKVM

•Upto5userscanshareasingleremotesession

•Multi-levelaccountaccess:Administrator and User account types.

•Remoteauthenticationsupport;RADIUSandLDAP/S

•SupportsbothIPv4andIPv6

•PDUControl-AddIPPDUsasdevicesthatcanbecontrolledbytheKVM.AssignindividualportsontheKVMtoaPDUporttopowercycle

or power off/on the computer/server connected to that port.

•BIOSlevelcontroltoanyserver’sbrandandmodel,regardlessoftheserverconditionandnetworkconnectivity.Coverstheentirespectrum

of crash scenarios.

•CompatiblewithWindowsandLinuxoperatingsystems.

•Connectcomputer/serversupto100ft.(30m.)awayfromtheKVMusinginexpensiveCat5e/6cablingandB078-101-USB2,

B078-101-USB-1 and B078-101-PS2 SIUs

•Java-basedapplicationallowscontrolofatargetserverviawebbrowserfromanylocationoverasecuredIPconnection.

•Featurestwo10/100MbpsLANports,sothatifonefails,theothertakesover.

•Supportsthehighestsecuritystandardsforencryption(128-bitAESandHTTPS).

•VirtualMediaallowsan.isolelocatedinaSharedfolderofaSAMBAorNFSservertobemountedtoaTargetServerandaccessedasif

it were directly stored on it.

•SupportsVirtualMediadatatransferratesupto12Mbps(B078-101-USB2required).AB078-101-USB-1canbeusedtoprovideVirtual

Media support, but only at speeds up to 1Mbps.

•Eventlogrecordseventsthattakeplaceontheinstallation,suchaslogins,reboots,networksettingschanges,etc..

•FeaturestwoRJ45serialportsforconnectingserialmanageabledevices,suchasPDUs,rewalls,androuters.

•AllowsforsystemsentmessagestoSNMPservertonotifyofLANfailures.

•AllowsfortheinstallationofaSSLcerticatetoensuresecuretransactionsbetweentheWebserversandbrowsers.

•GraphicalOSDandtoolbarsprovideconvenient,user-friendlyremoteoperation.

•TextbasedOSDprovidesconvenient,user-friendlylocaloperation.

•Supportsvideoresolutionsupto1920x1080@60Hz.(B070-consoleKVMsarelimitedtovideoresolutionsupto1366x768atthe

localconsole.)

•Flashupgradeablermwareoverthenetwork.

14-03-051 93-32D5.indd 3 3/14/2014 9:52:16 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	NetCommander B072-008-1-IP
Innebygd skjerm:	Ja
Vekt:	2080 g
Bredde:	482.6 mm
Dybde:	169.7 mm
Høyde:	43.7 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Maksimal oppløsning:	1920 x 1080 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	2990 g
Antall USB 2.0-porter:	3
Sertifisering:	UL 60950-1 (USA), CSA (Canada), FCC Part 15 Class A, CE IEC 60950-1
Kablingsteknologi:	10/100Base-T(X)
Nettverksstandard:	IEEE 802.3, IEEE 802.3u
Antall brukere:	2 bruker(e)
Antall datamaskiner:	8
Lydtilkoblinger:	Nei
Produktfarge:	Sort
Pakkedybde:	584.2 mm
Pakkehøyde:	109.2 mm
Pakkebredde:	261.6 mm
Antall VGA (D-Sub)-porter:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	12
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85176200
Rack-kapasitet:	1U
Sikkerhetsalgoritmer:	128-bit AES, HTTPS, SSL/TLS
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332183443
Masterkassens (ytterkassens) bruttovekt:	6800 g
Masterkassens (ytterkassens) lengde:	596.9 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	281.9 mm
Masterkassens (ytterkassens) høyde:	243.8 mm
Video tilkoblingstype:	VGA
