Side 1/58

Owner’s Manual

NetCommander

Cat5 KVM Switch

Models: B070-008-19-IP, B070-016-19-IP, B072-008-1-IP, B072-016-1-IP

(Series Number: AG-00C3)

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $50 value!

www.tripplite.com/warranty

Table of Contents

Legal Notice............................3

1. Product Overview......................3

1.1 Features and Beneﬁts ........................3

1.2 Terminology ................................4

1.3 Target Server Compatibility ....................4

1.4 Client Computer Compatibility..................4

1.5 Safety ....................................4

1.6 System Components .........................5

1.7 The NetCommander IP Unit ....................6

1.8 Rackmounting the NetCommander IP ............8

1.8.1 Standard Console KVM Switch Instructions...........8

1.8.2 2-Post Rack Console KVM Switch Instructions ........8

1.9 Connecting the System .......................9

1.10 Initial Settings (Default IP Address) ............9

2. Web Conﬁguration Interface .............13

2.1 Logging Into the Web Conﬁguration Interface......13

2.2 Web Conﬁguration Interface Layout .............14

2.3 My Targets Section ..........................15

2.4 Conﬁguration Section ........................16

2.4.1 Firmware Upgrade ............................17

2.4.2 Backup/Restore ..............................19

2.4.3 SSL Certiﬁcate ..............................20

2.4.4 Device ....................................21

2.4.5 Users .....................................22

2.4.6 Switch Conﬁguration ..........................24

2.4.7 User Targets ................................25

2.4.8 Power Devices...............................25

2.4.9 Power Outlets ...............................27

2.4.10 Serial Ports ................................28

2.4.11 Security ..................................28

2.4.12 Authentication..............................30

2.4.13 Date & Time ...............................34

2.5 Password Section ...........................34

2.6 Events Section..............................35

3. Conducting a Remote Session............36

3.1 Starting a Remote Session ....................36

3.2 Remote Session Toolbar ......................37

3.2.1 Pin Toolbar .................................37

3.2.2 Session ...................................37

3.2.3 Video .....................................39

3.2.4 Power.....................................40

3.2.5 Keys......................................41

3.2.6 Mouse ....................................43

3.2.7 Server/Serial ................................46

3.2.8 Full Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

3.2.9 Logout ....................................46

3.3 Shared Session .............................46

3.4 Exclusive Session ...........................46

4. Local Console ........................47

4.1 Move Label (F1) .............................47

4.2 Tuning (F5) .................................47

4.3 Power Management ..........................48

4.4 (F2) Setting ................................48

5. Serial Port Pinout .....................51

6. Security Certiﬁcate Installation ..........51

7. Technical Speciﬁcations ................57

8. Video Resolution and Refresh Rates .......58

9. Warranty & Product Registration..........58

Legal Notice

This manual and the software described in it are furnished under license, and may be used or copied only in accordance with the terms

of such license. The content of this manual is provided for informational use only, and is subject to change without notice. It should not in

and of itself be construed as a commitment by Tripp Lite, which assumes no responsibility of liability for any errors or inaccuracies that may

appear in this book.

The software that accompanies this manual is licensed for use by the Licensee only, in strict accordance with the software license

agreement, which the Licensee should read carefully before commencing use of the software. Except as permitted by the license, no part

of this publication may be reproduced, stored in retrieval system, or transmitted in any form or by any means, electronic, mechanical,

recording, or otherwise, without the prior written permission of Tripp Lite.

1. Product Overview

1.1 Features and Beneﬁts

• Directly connect up to 16 (B070-016-19-IP or B072-016-1-IP) or 8 (B070-008-19-IP or B072-008-1-IP) computers/servers.

• Up to 2 users (1 local, 1 remote) can simultaneously access the KVM

• Up to 5 users can share a single remote session

• Multi-level account access: Administrator and User account types.

• Remote authentication support; RADIUS and LDAP/S

• Supports both IPv4 and IPv6

• PDU Control - Add IP PDUs as devices that can be controlled by the KVM. Assign individual ports on the KVM to a PDU port to power cycle

or power off/on the computer/server connected to that port.

• BIOS level control to any server’s brand and model, regardless of the server condition and network connectivity. Covers the entire spectrum

of crash scenarios.

• Compatible with Windows and Linux operating systems.

• Connect computer/servers up to 100 ft. (30 m.) away from the KVM using inexpensive Cat5e/6* cabling and B078-101-USB2,

B078-101-USB-1 and B078-101-PS2 SIUs

• Java-based application allows control of a target server via web browser from any location over a secured IP connection.

• Features two 10/100 Mbps LAN ports, so that if one fails, the other takes over.

• Supports the highest security standards for encryption (128-bit AES and HTTPS).

• Virtual Media allows an .iso ﬁle located in a Shared folder of a SAMBA or NFS server to be mounted to a Target Server and accessed as if

it were directly stored on it.

• Supports Virtual Media data transfer rates up to 12Mbps (B078-101-USB2 required). A B078-101-USB-1 can be used to provide Virtual

Media support, but only at speeds up to 1Mbps.

• Event log records events that take place on the installation, such as logins, reboots, network settings changes, etc..

• Features two RJ45 serial ports for connecting serial manageable devices, such as PDUs, ﬁrewalls, and routers.

• Allows for system sent messages to SNMP server to notify of LAN failures.

• Allows for the installation of a SSL certiﬁcate to ensure secure transactions between the Web servers and browsers.

• Graphical OSD and toolbars provide convenient, user-friendly remote operation.

• Text based OSD provides convenient, user-friendly local operation.

• Supports video resolutions up to 1920 x 1080 @ 60Hz. (B070-console KVMs are limited to video resolutions up to 1366 x 768 at the

local console.)

• Flash upgradeable ﬁrmware over the network.

* To ensure proper functionality, shielded Cat5e/6 cable must be used with the B078-101-USB2, and is recommended for all other SIUs for best performance.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	NetCommander B072-016-1-IP
Innebygd skjerm:	Nei
Vekt:	2130 g
Bredde:	482.6 mm
Dybde:	169.7 mm
Høyde:	43.7 mm
Maksimal oppløsning:	1920 x 1080 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	2990 g
Sertifisering:	UL 60950-1 (USA), CSA (Canada), FCC Part 15 Class A, CE IEC 60950-1
On Screen Display (OSD):	Ja
Antall brukere:	2 bruker(e)
Antall porter:	16
Produktfarge:	Sort
Pakkedybde:	579.1 mm
Pakkehøyde:	109.2 mm
Pakkebredde:	256.5 mm
Kabler inkludert:	Seriell
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8471.80.1000
Ekstern strømadapter:	Ja
DC-inngangskontakt:	Ja
Rack-kapasitet:	1U
Ethernet/bredbåndsforbindelse:	Ja
Rack-montering:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	20037332141600
Masterkassens (ytterkassens) bruttovekt:	6760 g
Masterkassens (ytterkassens) lengde:	591.8 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	281.9 mm
Masterkassens (ytterkassens) høyde:	243.8 mm
Video tilkoblingstype:	VGA
Tastatur tilkoblingstype:	USB, PS/2
Mus tilkoblingstype:	USB, PS/2
