Owner’s Manual

NetDirector Cat5 IP

KVM Switches

Models:

B064-008-01-IPG, B064-016-01-IPG, B064-016-02-IPG, B064-016-04-IPG, B064-032-01-IPG,

B064-032-02-IPG, B64-032-04-IPG and B064-064-08-IPG

Package Contents

This package contains:

(1) B064-008-01-IPG, B064-016-01-IPG,

B064-016-02-IPG, B064-016-04-IPG,

B064-032-01-IPG, B064-032-02-IPG,

B64-032-04-IPG or B064-064-08-IPG

(2) Power Cords – C13 to 5-15P Connectors

(1) RJ45 Female to DB9 Male Adapter

(1) Grounding Wire

(1) Rack-Mount Kit

(1) Set of Foot Pads

(1) CD (Includes Owner’s Manual,

Quick Start Guide and Device Files)

(1) Quick Start Guide

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

www.tripplite.com/warranty

Table of Contents

Table of Contents ........................................2

Introduction ............................................3

Important Safety Notice....................................3

Features ................................................3

Remote Console Computer Requirements......................4

Connected Computer/Server Requirements.....................4

Server Interface Units (SIUs)................................4

Supported Operating Systems ...............................4

Supported Browsers.......................................5

Components .............................................5

Hardware Setup .........................................7

General Safety Instructions .................................7

Stacking ................................................8

Rack Mounting...........................................8

Single-Stage Installation ...................................8

Two-Stage Installation .....................................9

Laptop USB Console (LUC) ...............................10

Hot Plugging ...........................................10

Powering Off & Restarting ................................10

Port ID Numbering ......................................10

Super Administrator Setup ...............................11

First Time Setup.........................................11

Network Setup - IP Address Determination....................11

Changing the Super Administrator Login .....................13

Logging Into the B064-Series KVM Switch..................13

Local Console Login .....................................13

Browser Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

AP Windows Client Login .................................14

AP Java Client Login .....................................15

OSD Operation.........................................16

The OSD Main Page .....................................16

OSD Tab Bar ...........................................17

Port Access.............................................17

Connections ............................................18

History ................................................22

Favorites...............................................23

User Preferences ........................................24

Sessions ...............................................25

Access ................................................25

Port Conﬁguration .......................................26

Multi-View Conﬁguration .................................28

Blade Conﬁguration......................................29

User Management .......................................30

Device Management .....................................36

Device Information ......................................36

Operating Mode .........................................37

Network ...............................................37

Advanced Network Management Settings.....................39

OOBC ................................................47

Security ...............................................48

Date/Time..............................................53

Blade Server Conﬁguration ................................53

Log ...................................................55

Maintenance............................................56

Download..............................................59

Remote Session Operation ...............................60

Control Panel ...........................................60

The OSD Toolbar ........................................71

Multiuser Operation......................................73

Auto Scanning ..........................................73

The Log Server.........................................74

Installation .............................................74

Starting Up.............................................74

The Menu Bar ..........................................74

Conﬁgure ..............................................75

Events.................................................76

Options................................................77

Help ..................................................77

The Log Server Main Screen - Overview .....................77

Appendix..............................................79

Keyboard Emulation .....................................79

General Operation Troubleshooting..........................80

Administration Troubleshooting ............................80

Mouse Troubleshooting ...................................81

Virtual Media Troubleshooting .............................81

AP Windows Client Troubleshooting ........................81

WinClient ActiveX Viewer Troubleshooting ...................82

Panel Array Mode Troubleshooting ..........................82

Java Applet & AP Java Client Troubleshooting.................82

Log Server Troubleshooting ...............................83

Sun Systems Troubleshooting ..............................83

Speciﬁcations ..........................................84

Factory Default Settings...................................84

Serial Adapter Pin Assignments.............................84

Fan Location & Speed Information ..........................85

Temperature Sensor Location ..............................85

Product Registration ....................................86

Introduction

Features

Important Safety Notice

BATTERY SAFETY NOTICE

• There is a risk of explosion if the battery is replaced with an incorrect type. Dispose of used batteries

according to the relevant instructions.

BATTERIE AVIS DE SÉCURITÉ

• II existe un risque d’explosion si la batterie est remplacée par un incorrect tapez. Jeter les piles usagées selon

la pertinente instructions.

• Directly connect up to 8 (B064-008-01-IPG),

16 (B064-016-01-IPG, B064-016-02-IPG, B064-016-04-IPG),

32 (B064-032-01-IPG, B064-032-02-IPG, B064-032-04-IPG) or

64 (B064-064-08-IPG) computers/servers

• Accomodate additional computers/servers in a two-level cascade

installation

• Two 10/100/1000 Mbps network connections for redundant LAN or

two IP operation

• Supports both IPv4 and IPv6

• Blade server support

• Supports up to 1 (B064-008-01-IPG, B064-016-01-IPG,

B064-032-01-IPG) or 2 (B064-016-02-IPG, B064-032-02-IPG) or

4 (B064-016-04-IPG, B064-032-04-IPG) or 8 (B064-064-08-IPG)

remote sessions

• 1 Local and 1 Remote User can simultaneously access the

B064-008-01-IPG, B064-016-01-IPG or B064-032-01-IPG

• 1 Local and 2 Remote Users can simultaneously access the

B064-032-02-IPG or B064-016-02-IPG

• 1 Local and 8 Remote Users can simultaneously access the

B064-064-08-IPG

• 1 Local and 4 Remote Users can simultaneously access the

B064-016-04-IPG or B064-032-04-IPG

• Up to 32 users can remotely share one user port

• Create up to 64 user accounts

• Multi-level authentication: super administrator; administrator; user

• Advanced security features include password protection and

advanced encryption technologies – 1024 bit RSA; 56 bit DES; 256

bit AES; and 128 bit SSL

• RJ45 connectors and Cat5e cable allow for a more efﬁcient

installation

• Browser access can be disabled – Windows

and Java GUI AP

programs provided for non-browser connectivity

• Graphical OSD and toolbars provide convenient, user-friendly

operation

• Full-screen graphical OSD for the local console

• Full-screen or sizable remote desktop window; in full-screen mode

the remote desktop display scales to user’s monitor display size

• Panel Array Mode displays up to 32 ports at the same time

• High video resolution: up to 1920 x 1200 @ 60Hz – 24 bit color

depth for the local console; up to 1920 x 1200 @ 60Hz with 24 bit

color depth for remote sessions at up to 164 ft. (50 m)

• Features advanced FPGA graphics processor for improved video

quality

• Multi-language support; OSD can be displayed in English, Spanish,

French, German, Russian, Italian, Japanese, Korean, traditional

Chinese and simpliﬁed Chinese

• Software (on-screen) keyboard

• UltraSync for USB mice – local and remote mouse movement are

the same – no need to constantly re-sync the two movements

• Windows-based Log Server

• Support all major server platforms and VT100-based serial devices

• Support multi-platform server environments: PS/2 and USB

• Support 10Base-T, 100Base-T, 1000Base-T, Auto-Sense, TCP/IP,

HTTP, DNS, DHCP, UDP, ARP, Ping

• Remote authentication support: RADIUS, LDAP, LDAPS, and

Active Directory

• Flash upgradeable ﬁrmware over the network

• Server Interface Unit (SIU) information is stored by the KVM

switch. When switched to a different port, the port settings (Port

OS, OS Language, etc.) for the SIU are transferred along with it

• Virtual Media allows computers connected to the KVM switch by

a B055-001-USB-V2 SIU to access DVD/CD drives, ﬂash drives

and other storage media as if they were directly connected to the

computer (works in either the operating system or BIOS level)

• Includes three USB ports on the front of the unit that can be

used for an external keyboard and mouse or for virtual media

functionality

• Dual power supplies allow the unit to continue running in the event

one power supply ceases to receive power. If one power supply fails,

the other powers supply takes over to keep the unit powered and

functional.

• Temperature sensors determine if fans are needed to cool the

device and at what speed. The fan speed increases/decreases along

with the temperature, using energy more efﬁciently and increasing

the life of the fans and switch.

• Track critical events on the installation via SMTP email

notiﬁcation, SNMP traps, the included Windows-based Log Server

or Syslog server

• Users can choose between any combination of 56-bit DES, 168-

bit 3DES, 256-bit AES, 128-bit RC4 or Random for independent

Keyboard/Mouse, video and virtual media data encryption

• Support Exit Macros

• BIOS level access

• Supports Link Local IPv6 Address and IPv6 Stateless

Autoconﬁguration protocols

• Modem out of band Dial In, Dial Out, Dial Back support

• Automated Certiﬁcate Signing Request (CSR) creation utility

• Supports importing third party CA certiﬁcates

• Supports IPS 140-2 level 1 security standards

• Local monitor’s EDID information stored in connected Server

Interface Units (SIUs) for optimal display resolution

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	NetDirector B064-064-08-IPG
Innebygd skjerm:	Nei
Vekt:	7390 g
Bredde:	433.3 mm
Dybde:	87.9 mm
Høyde:	405.9 mm
Strømkilde:	AC
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	Mini-USB B, USB Type-A
Maksimal oppløsning:	1920 x 1200 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	8630 g
Sertifisering:	FCC, REACH
On Screen Display (OSD):	Ja
Antall brukere:	9 bruker(e)
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	64
Videobåndbredde:	60 Hz
Lydtilkoblinger:	Ja
Produktfarge:	Sort
HD-type:	Full HD+
Pakkedybde:	175.3 mm
Pakkehøyde:	575.1 mm
Pakkebredde:	505 mm
Kabler inkludert:	AC, PS/2, USB
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	75
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	0 - 80
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8471.80.1000
Kroppsmateriale:	Metall
Rack-kapasitet:	1U
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Ja
Plugg inn og spill:	Ja
Guide for hurtiginstallering:	Ja
Produkter per masterkasse (ytterkasse):	1 stykker
Innput-strøm:	1 A
Gummibein:	Ja
Maksimal opereringsrekkevidde:	50 m
Video tilkoblingstype:	VGA
Rack-montert sett:	Ja
Tastatur tilkoblingstype:	USB, PS/2
Mus tilkoblingstype:	USB, PS/2
Konsoll porter:	DVI-D, USB A
Trykk på knapp:	Ja
Automatisk skanningsforsinkelse (min.):	1 s
Scanningsintervall:	1,3,4,5,8,10,15,20,25,30,35,40,45,50,55,60,70,80,90,99,100,240,250,255 s
Automatisk skanningsforsinkelse (maks.):	255 s
