Side 1/20

Owner’s Manual

Unmanaged Desktop

Network Gigabit Switches

Models: NG5 / NG5P / NG8 / NG8P

Español 7 • Français 13

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

16-04-017-9335AB.indb 1 4/11/2016 3:29:41 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS!

This manual contains important instructions and warnings that

should be followed during the installation, operation and storage of

this Tripp Lite product. Failure to heed these warnings may affect

your warranty.

Switch Location Warnings

• The switch is designed for indoor use only, in a controlled environment, away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• For best performance, maintain an indoor temperature between 32º F and 104º F (0º C

and 40º C) with relative humidity between 10% and 90% (non-condensing).

• Leave adequate space around all sides of the switch for proper ventilation.

• Keep the switch away from high-frequency, strong-current devices (e.g., radio transmitting

stations, transmitters and broadband ampliﬁers).

• Use electromagnetic shielding (if required).

• Securely place the switch on a sturdy, ﬂat surface.

• Improper installation can cause product damage that is not covered by the warranty.

• Do not expose the network switch’s connected networking cables to outdoor elements.

• Do not use this product near water (e.g., in a wet basement, or near a swimming pool).

• Use of this equipment in life support applications where failure of this equipment

can reasonably be expected to cause the failure of the life support equipment or to

signiﬁcantly affect its safety or effectiveness is not recommended. Do not use this

equipment in the presence of a ﬂammable anesthetic mixture with air, oxygen or nitrous

oxide.

Switch Connection Warnings

• Keep the switch’s input power off during installation.

• Use only the power adapter included with the switch.

• Make sure the power supply voltage matches the speciﬁcations indicated on the switch.

• Do not drill into or attempt to open any part of the switch housing. There are no user-

serviceable parts inside.

• Do not attempt to modify the switch, including the input plugs and power cables.

• Do not attempt to use the switch if any part of it becomes damaged.

• Make sure network cables are properly seated. A clicking sound will be made when a

cable is installed correctly.

• If the power adapter is damaged, do not attempt to connect the switch. Contact a Tripp

Lite Service Representative for assistance.

• Never attempt to install or use the switch during a thunderstorm.

16-04-017-9335AB.indb 2 4/11/2016 3:29:41 PM

5-Port Models:

NG5

NG5P

Product Features

5 Port 10/100/1000Mbps Unmanaged Switch

16-04-017-9335AB.indb 3 4/11/2016 3:29:41 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	NG5
Vekt:	250 g
Bredde:	78 mm
Dybde:	140 mm
Høyde:	27.9 mm
Opprinnelsesland:	China
Pakkevekt:	410 g
10G støtte:	Nei
AC-inngangsspenning:	100 - 240 V
Produktfarge:	Sort
Pakkedybde:	162.6 mm
Pakkehøyde:	121.9 mm
Pakkebredde:	96.5 mm
Harmonisert system (HS)-kode:	8517.62.0020
Rack-montering:	Nei
Svitsjtype:	Uhåndtert
Antall Basic switching RJ-45 Ethernet-ports:	5
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Størrelse på adressetabell:	- oppføringer
Ruting/svitsjekapasitet:	- Gbit/s
Strømforsyning medfølger:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332194777
Masterkassens (ytterkassens) bruttovekt:	14880 g
Masterkassens (ytterkassens) lengde:	335.3 mm
Produkter per masterkasse (ytterkasse):	30 stykker
Masterkassens (ytterkassens) bredde:	622.3 mm
Masterkassens (ytterkassens) høyde:	317.5 mm
Strømtilkobling:	DC-inngang
