Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

Unmanaged Network Gigabit

Ethernet Switches with POE

Models: NG5POE, NG8POE, NG16POE

Español 10 • Français 19

16-08-358-9335EB.indb 1 8/23/2016 2:45:41 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS!

This manual contains important instructions and warnings that

should be followed during the installation, operation and storage of

this Tripp Lite product. Failure to heed these warnings may affect

your warranty.

Switch Location Warnings

• The switch is designed for indoor use only, in a controlled environment, away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• For best performance, maintain an indoor temperature between 32º F and 104º F (0º C

and 40º C) with relative humidity between 10% and 90% (non-condensing).

• Leave adequate space around all sides of the switch for proper ventilation.

• Keep the switch away from high-frequency, strong-current devices (e.g., radio

transmitting stations, transmitters and broadband ampliﬁers).

• Use electromagnetic shielding (if required).

• For rackmount conﬁguration, ensure that both the rack and switch are properly grounded.

• If the switch is not rack mounted, securely place it on a sturdy, ﬂat surface.

• The electrical outlets supplying power to the equipment should be installed near the

equipment and easily accessible.

• Improper installation can cause product damage that is not covered by the warranty.

• Do not expose the network switch’s connected networking cables to outdoor elements.

• Do not use this product near water (e.g., in a wet basement, or near a swimming pool).

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to signiﬁcantly

affect its safety or effectiveness is not recommended. Do not use this equipment in the

presence of a ﬂammable anesthetic mixture with air, oxygen or nitrous oxide.

16-08-358-9335EB.indb 2 8/23/2016 2:45:41 PM

Package Includes

• NG5POE, NG8POE or NG16POE Unmanaged Network Gigabit Ethernet Switch with POE

• Detachable Power Cord

• Mounting Brackets (2)

• Screws (8)

• Rubber feet (4)

• Owner’s Manual

Important Safety Instructions

Switch Connection Warnings

• Keep the switch’s input power off during installation.

• Use only the power adapter included with the switch.

• Make sure the power supply voltage matches the speciﬁcations indicated on the switch.

• Connect the switch to an outlet that is in accordance with your local building codes and

that is adequately protected against excess currents, short circuits and earth faults.

• Do not connect the switch to an ungrounded outlet or to extension cords or adapters that

eliminate the connection to ground.

• Do not drill into or attempt to open any part of the switch housing. There are no user-

serviceable parts inside.

• Do not attempt to modify the switch, including the input plugs and power cables.

• Do not attempt to use the switch if any part of it becomes damaged.

• Make sure network cables are properly seated. A clicking sound will be made when a

cable is installed correctly.

• If the power adapter is damaged, do not attempt to connect the switch. Contact a

Tripp Lite Service Representative for assistance.

• Never attempt to install or use the switch during a thunderstorm.

16-08-358-9335EB.indb 3 8/23/2016 2:45:41 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bryter
Modell:	NG8POE
Vekt:	1860 g
Bredde:	279.9 mm
Dybde:	180.1 mm
Høyde:	43.9 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	2680 g
Nettverksstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Auto MDI/MDI-X:	Ja
10G støtte:	Ja
AC-inngangsspenning:	100 - 240 V
Jumbo rammer:	9000
Produktfarge:	Sort
Pakkedybde:	436.9 mm
Pakkehøyde:	76.2 mm
Pakkebredde:	243.8 mm
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 70 °C
Harmonisert system (HS)-kode:	8517.62.0020
Formfaktor:	1U
Driftshøyde:	0 - 3000 m
Relativ luftfuktighet under drift (H-H):	10 - 90
Rack-montering:	Ja
Monteringsbeslag inkludert:	Ja
AC-adapter bunt:	Ja
Svitsjtype:	Uhåndtert
Antall Basic switching RJ-45 Ethernet-ports:	8
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Størrelse på adressetabell:	- oppføringer
Ruting/svitsjekapasitet:	16 Gbit/s
Strøm over Ethernet (PoE):	Ja
Power over Ethernet (PoE) effekt per port:	30 W
Antall Power over Ethernet plus (PoE+)-ports:	8
Plugg inn og spill:	Ja
Jumbo Frames-støtte:	Ja
Full tosidig:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332194784
Masterkassens (ytterkassens) bruttovekt:	14290 g
Masterkassens (ytterkassens) lengde:	454.7 mm
Produkter per masterkasse (ytterkasse):	5 stykker
Masterkassens (ytterkassens) bredde:	424.2 mm
Masterkassens (ytterkassens) høyde:	271.8 mm
Total Power over Ethernet (PoE)-budsjett:	140 W
MAC-adresse automatisk læring støttes:	Ja
MAC-adresse automatisk aldring støttes:	Ja
