Version 1.1 ©Copyright 20 , Ambient LLC. All Rights Reserved. Page 1 20
Ambient Weather WH31LA Leak Detector User Manual
Table of Contents
1. Introduction ..................................................................................................................................... 1
2. Features ........................................................................................................................................... 2
3. Getting Started ................................................................................................................................ 3
4. Setup Guide ..................................................................................................................................... 3
4.1 Batteries and Dip Switches ..................................................................................................... 3
5. Wireless Monitoring ........................................................................................................................ 5
5.1 -2000 / WS-5000 Display and Sensor Registration .......................................................... 5 WS
6. Introduction to Ambient Weather Network ..................................................................................... 7
7. Specications .................................................................................................................................. 8
7.1 Sensor Specications ............................................................................................................. 8
7.2 Wireless Specifications .......................................................................................................... 8
7.3 Power Consumption ............................................................................................................... 8
8. Troubleshooting .............................................................................................................................. 8
9. Liability Disclaimer ........................................................................................................................ 8
10. FCC Statement............................................................................................................................ 9
11. Warranty Information ................................................................................................................. 9
12. California Prop 65 .................................................................................................................... 10
1. Introduction
Thank you for your purchase of the Ambient Weather Leak Detector sensor. The following WH31LA
user guide provides step by step instructions for installation, operation, and troubleshooting. To
download the latest manual and additional troubleshooting tips, please visit:
https://ambientweather.com/faqs/question/tags/tag/WH31LA/
-or-
The leak detection sensor is not a stand-alone device and requires a WS-2000, WS-5000 or
Version 1.1 ©Copyright 20 , Ambient LLC. All Rights Reserved. Page 2 20
OBSERVERIP to view and upload the data to the Ambient Weather N work. et
To see if your weather station is compatible, please visit:
https://ambientweather.com/amwh31la.html
The following -2000 and WS-5000 console rmware versions or greater support the leak detecto WS r:
Firmware revision number: V1.6.0
WiFi Firmware: AMBWeatherV4.2.0
For details on updating the rmware, consult your weather station user manual.
No
Item
1
Alarm (inside the device)
2
Battery cover
3
Sensing surface
4
LED indicator
5
Dip Switches for Multi-channel operation and sensitivity level
Figure 1
2. Features
Detects water every 3 seconds.
Emits loud 90 db alarm when triggered. a
High or low sensor sensitivity selectable to meet different requirements.
View live sensor data on the Ambient Weather Network - AmbientWeather.net or
Version 1.1 ©Copyright 20 , Ambient LLC. All Rights Reserved. Page 3 20
Trigger email alerts, text messages or trigger IFTTT actions.
Each console supports up to 4 leak detectors.
Battery level status displayed on AmbientWeather.net or in the app
3. Getting Started
The Ambient Weather WH31LA leak detection sensor includes the following:
QTY
Item
1
Leak Detector 3.5 x 1.5 x 1" (95 x 45 x 22.8 ) : mm
1
User Manual
4. Setup Guide
4.1 Batteries and Dip Switches
The leak detector requires 2 x AAA batteries (not included). We recommend Energizer Lithium
batteries for longer life and a wider operating temperature range.
Remove the battery door as shown in Figure 2.
Figure 2
Before inserting the batteries, nd the dip switches instruction above the battery compartment
and set the sensor sensitivity level and channel number:
