Ambient Weather WM-4 Bruksanvisning
Les nedenfor 📖 manual på norsk for Ambient Weather WM-4 (2 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 9 personer og ble vurdert med 4.3 stjerner i gjennomsnitt av 5 brukere
Side 1/2
Mode
Keys
Mode/ On/ Off
SET/ EL
Units
Wind speed
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Max. Wind
speed
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Avg. Wind
speed
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Compass
Change mode
(Hold to turn power ON/ OFF)
Hold to enter Compass
Calibration
Hold to mark
direction
Crosswind
Exit to compass
Hold to enter Compass
Calibration
Headwind
Headwind
Exit to compass
Hold to enter Compass
Calibration
Crosswind
Compass
Calibration
---------------
Exit to compass
---------------
Temperature
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Wind Chill
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Humidity
Change mode
(Hold to turn power ON/ OFF)
---------------
---------------
Wet Bulb
Change mode
(Hold to turn power ON/ OFF)
----
Change Units
Dew Point
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Comfort Index
Change mode
(Hold to turn power ON/ OFF)
Hold to enter Solar Factor
Setting
Change Units
Solar Factor
Setting
---------------
Exit to Comfort Index
Advance adjust
Delta T
Change mode
(Hold to turn power ON/ OFF)
---------------
Change Units
Ambient Weather WM-4
User Instruction Manual (Ver. 1.0)
Temperature, Wind Chill, Wet Bulb, Comfort Index, Delta T:
°
F->
°
C
Compass Calibration
If necessary, to correct for the presence of
ferrous metals, the compass can be calibrated.
Go to compass mode press and hold SET/EL
key till display shows “COMPASS CAL”
(blinking). Turn the unit in a vertical position as
shown. Turn the unit around twice, 15 sec per
turn, as shown. After completing the 2 turns
press key to conrm calibration. If the SET/EL
display shows “END” the calibration is
successful. If the display shows “ERR” redo the
calibration process.
Getting Started
Open your WM-4 to 180
o
as shown. If using a
tripod, open your WM-4 to a 90
o
angle as shown
above to access the tripod fitting.
To turn the unit on or off, press and hold Mode
key for about 3 sec. You can turn o the unit at
any mode. If the unit is idle for 5 minutes, it will
auto shut down to preserve battery life.
When taking wind measurements by hand, make sure to
keep the WM-4 at arm’s length from the body with the
display facing towards you so the wind will enter the wind
impeller through the rear. Use the wind vane to orient the
wind meter so you are on the wind’s axis. This will give you
the most accurate measurement.
CAUTION: The WM-4 is very accurate at low and mid-range
air speeds. Consistent use at very high speeds, such as
from a fast-moving car, will damage the impeller’s bearing
and reduce its accuracy. See below for impeller
replacement.
Digital Wind Direction
Point the WM-4 directly into the wind and select Compass
mode. The edge of the wind vane will point directly towards
you. Wind direction is displayed digitally and in compass
points.
The compass feature can also compute the cross and
head/tail wind. Point the meter in the direction of travel or
target and get a steady compass reading. Press and hold
Units key until MARK stops blinking. Release key Units
and point the meter into the wind until you have a steady
compass reading. Press and hold key until MARK Units
stops blinking. The meter will display cross wind and to view
head wind press the Key. The computed cross and Units
head/tail wind may indicate a minus ( ) sign. The minus (– –)
sign will indicate the wind is coming from the back, while no
sign will indicate that the wind is coming from the front. To
exit, press . Mode
Using the wind meter functions
When the unit is turned on for the rst time, the default
mode is wind speed. Going to other modes or features is
simply done by pressing the M button. ode
Pressing Key at any mode (except Compass and Units
Humidity) changes the unit to your preferred measurement
unit. Units of measurement sequence is shown below for
each model.
Mode Sequence
Press the Mode button to sequence the following
parameters:
Wind Speed
Max Wind Speed
Avg. Wind Speed
Compass
Temperature
Wind Chill
Humidity
Wet Bulb Temperature
Comfort Index
Delta T
Units Sequence
Select the Units button to display the parameter you wish to
sequence units:
Current, Max, Avg. Windspeed:
Mph->Kmph->mps->fpm->Beaufort Scale->Knots
Setting the C omfort Index™
Accuweather.com® Comfort Index™ is the effect of temp,
relative humidity, wind speed & sun intensity on the human
body. You can adjust the formula based on sun intensity.
The solar factor has a range of 0 to 3.0 with a default setting
of 1.5 (medium sun intensity). Example: Full sun = 3.0;
Heavy clouds = 0. To change, press and hold key. SET/EL
Press key to adjust the current value of the solar Units
factor and press to conrm and exit the setting SET/EL
mode.
Replacing the Battery (All models)
The unit uses a CR2032 Lithium battery. Turn the unit to the
back. Use a coin to turn battery cover as indicated by the
arrow. Insert the battery with the printed side facing you and
close the battery door.
Changing the Wind Impeller (All models)
WM-4 impellers can be replaced. Contact
AmbientWeather.com for parts and instructions.
Your instrument has a 2-year warranty. Please save your
invoice for verication and contact AmbientWeather.com for
questions or service:
877-413-8800, 8am-4pm M-F (Arizona Time)
website: www.ambientweather.com
email: support@ambientweather.com
Sequence for WM 200
Wind s displays real time wind speed peed –
Max. wind speed displays max. wind speed –
Avg. wind speed displays 10-sec average –
Compass
Temperature
WindChill
Max. / Avg. / Wind Speed
MPH >KMPH >MPS >FPM >BF >KNT ---- ---- ---- ---- ----
Temp. / Wind Chill
0
F >----
0
C
Sequence for WM 300
Wind speed displays real time wind speed –
Max. wind speed displays the max. wind speed –
Avg. wind speed displays 10-sec average –
Compass
Temperature
WindChill
Humidity (Sensor is self-calibrating)
Wet Bulb
Dewpoint
Comfort Index
Delta Temperature
Key Function Matrix
Warranty
Ambient, LLC provides a 2-year limited warranty on this product
against manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is
valid only on products purchased and only to the original
purchaser of this product. To receive warranty service, the
purchaser must contact Ambient, LLC for problem determination
and service procedures.
Warranty service can only be performed by a Ambient, LLC. The
original dated bill of sale must be presented upon request as
proof of purchase to Ambient, LLC.
Your Ambient, LLC warranty covers all defects in material and
workmanship with the following specied exceptions: (1) damage
caused by accident, unreasonable use or neglect (lack of
reasonable and necessary maintenance); (2) damage resulting
from failure to follow instructions contained in your owner’s
manual; (3) damage resulting from the performance of repairs or
alterations by someone other than an authorized Ambient, LLC
authorized service center; (4 applications and uses that this )
product was not intended.
This warranty covers only actual defects within the product itself,
and does not cover claims based on misrepresentation by the
seller or performance variations resulting from installation-related
circumstances.
Wind Impeller
Wind Vane
Units
SET/ EL
Mode/ On/ Off
Tripod Fitting
1
2
3
4
5
6
7
8
9
