Version 1.4 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather -04 Wireless Indoor / Outdoor WS
Thermometer
Table of Contents
1. Introduction ..................................................................................................................................... 1
2. tting Started ................................................................................................................................ 1 Ge
2.1 Parts List ....................................................................................................................................... 1
2.2 Remote Thermometer Sensor Set Up ............................................................................................ 2
2.3 Display Console Set Up ................................................................................................................ 2
2.4 Sensor Operation Verication ................................................................................................ 3
4. Glossary of Terms ........................................................................................................................... 4
5. Specications .................................................................................................................................. 4
5.1 Wireless Specications ................................................................................................................. 4
5.2 Measurement Specications ......................................................................................................... 4
5.3 Power Consumption ...................................................................................................................... 4
7. Accessories ..................................................................................................................................... 5
9. FCC Statement ................................................................................................................................ 6
1. Introduction
Thank you for your purchase of the Ambient Weather -04 wireless indoor / outdoor thermometer. WS
The following user guide provides step by step instructions for installation, operation and
troubleshooting. To download the latest manual and additional troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/ws04
2. Getting Started
The -04 wireless indoor / outdoor thermometer consists of a display console (receiver), and a WS
wireless thermometer (remote transmitter).
2.1 Parts List
QTY
Item
1
Display Console
Frame Dimensions (LxWxH) 3.5 x 2.5 x 0.75 : in
LCD Dimensions (LxW) 1.5 x 1.25:
1
Thermometer transmitter
Dimensions (LxWxH): 2 0.5” x 2. ” x 1.0
Version 1.4 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 2
2.2 Remote Thermometer Sensor Set Up
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Pull down on the battery door to open the battery compartment, as shown in .2. Insert two Figure 1
fresh AAA batteries (with the negative terminal of the battery in contact with each spring). Lithium
batteries are recommended for cold weather environments. Slide the top lip of the battery door into
the battery compartment guide and snap the bottom battery door bracket into place.
The LED shown in .1 will light up (visible through the plastic) and then turn o. It will then Figure 1
ash about once per minute thereafter.
Figure 1
2.3 Display Console Set Up
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Move the remote thermometer at least 5’ away from the display console (if the sensor is too close, it
may not be received by the display console). Remove the battery door on the back of the display.
Insert two AAA (alkaline or lithium) batteries in the back of the display console, as shown in Figure 2.
All of the LCD segments will light up for a few seconds to verify all segments are operating properly.
The IN status bar will continuously ash once per second to conrm proper operation.
The console will instantly display indoor temperature. The outdoor temperature will display dashes
or .-, then update on the display within a few minutes. --
If the remote sensor does not update, please reference the troubleshooting guide in Section 6.
Version 1.4 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 3
Figure 2
Replace the battery door, and fold out the desk stand and place the console in the upright position.
Figure 3
2.4 Sensor Operation Verification
Verify the indoor and outdoor temperature match closely with the console and the remote thermometer
in the same location (about 5’ apart). The sensors should be within 4 (the accuracy is ± 2 ). °F °F
Allow about 30 minutes for both sensors to stabilize.
3. Remote Sensor Installation
water resistant, it is best to mount in a well protected area, such as an eve.
Use a screw or nail (not included) to affix the remote sensor to the wall, as shown in Figure 4.
