RADIO REPLACEMENT
R
INTERFACING SOLUTIONS
SOCGM-18
Radio Replacement Interface for
GM LAN 29 Bit Vehicles 2006-2015
- Supports Bose, non-Bose and Y-91 audio systems.
- Retains factory front and rear parking sensors.
PRODUCT FEATURES:
PARTS INCLUDED:
INSTALLATION INSTRUCTIONS:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.122122
1 of 2
SOCGM-18 Module SOCGM-18 Harness Antenna Adapter
NOTES:
1. Supports Rear Entertainment System with special order harness #CJA2333A (sold separately).
2. DOES NOT support ONSTAR.
AFTERMARKET
RADIO
Reverse
Red/White or
Violet/White
Amplifier Turn-on Blue/ White
+12V Constant Yellow
+12V ACC Red
Ground Black
Right Front (+) Gray
Right Front (-) Gray/Black
Right Rear (+) Violet
Right Rear (-) Violet/Black
TO FACTORY
HARNESS
16-Pin Black
Connector
Non Bose Bose
See below for Audio
connection options
RADIO REPLACEMENT
R
INTERFACING SOLUTIONS
SOCGM-18
Radio Replacement Interface for
GM LAN 29 Bit Vehicles 2006-2015
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.122122
VEHICLE APPLICATIONS:
2 of 2
a built-in audio level adaptor that outputs the proper audio level from the
8-pin connector on the SOCGM-18 harness to the GRAY female 8-pin connector
on the SOCGM-18 module. The module is also labeled “Bose” and “Non Bose”
to avoid confusion. (see picture below)
8-pin connector to the BLACK female 8-pin on the SOCGM-18 module.
BOSENON BOSE
It is set at half way by default. To adjust the volume, simply use
increase the volume and counter-clockwise to decrease the volume.
Chime
Volume
Adjustment
CHIME VOLUME ADJUSTMENT:
SELECTING THE AUDIO SYSTEM:
BUICK
2008-2017 Enclave
2006-2011 Lucerne
CADILLAC
2006-2011 DTS
2007-2014 Escalade
2007-2009 SRX
CHEVROLET
2007-2013 Avalanche*
2007-2008 Equinox
2008-2016 Express Van**
2006-2013, 2016 Impala / Impala SS
2014, 2016 Impala Classic
2006-2007 Monte Carlo
2007-2013 Silverado 1500-3500 Pickup*
2007-2014 Suburban*
2007-2014 Tahoe*
2009-2017 Traverse
GMC
2007-2016 Acadia
2017 Acadia Classic
2008-2017 Savana**
2007-2013 Sierra 1500-3500 Pickup*
2007-2014 Yukon*
HUMMER
2008-2009 H2
PONTIAC
2007-2009 Torrent
SATURN
2007-2009 Outlook
2008-2009 Vue
SUZUKI
2007-2008 XL7
