- Pre-programmed to retain factory Steering Wheel Controls.
- Voice Recognition Command from factory SWC.
- Supports Bose, non-Bose and Y-91 audio systems.
- Retains chime functions.
- Built-in chime volume adjustment.
- EIA color coded wiring for easy installation.
PRODUCT FEATURES:
PARTS INCLUDED:
INSTALLATION DIAGRAM:
SWRGM-48 MODULE SWRGM-48 HARNESS SWC CABLE
SWRGM-48
Radio Replacement Interface with Steering Wheel Control
Retention for select GM Class II Vehicles
TROUBLESHOOTING
LED
LIGHT
LED MODULE FEEDBACK
Solid blue
Flashing blue
Solid red Module providing 12V ACC
CAN not recognized
CAN recognized
12V ACC OFFRed off
A 91311
.cruxinterfacing.com
SWRGM-48
Radio Replacement Interface with Steering Wheel Control
Retention for select GM Class II Vehicles
2 of 8
R O P LA TADI RE CEM EN
SW E T IONC R ENT
+
R
INTERFACING SOLUTIONS
DIP SWITCH SETTINGS:
AFTERMARKET RADIO DIP SWITCH SETTINGS:
RADIO BRAND: DIP#: 1 2 3
Atoto, Dual, Fahrenheit, Jensen, Nakamichi,
Pioneer, Power Acoustik, Soundstream
Alpine
Clarion
Kenwood
JVC
Boss, Old Sony
New Sony (with CarPlay)
OFF ON ON
OFF ON ON
OFF ON ON
OFF OFF OFF
ON ON OFF
ON ON ON
ON OFF ON
ON OFF OFF
OFF ON OFF
SWC MODULE
DIP SWITCH
1 2 3
ON
NOTE:
radios, check the aftermarket radio’s manual to see if the SWC buttons need to be programmed.
4-PIN SWC CABLE
SELECTING THE AUDIO SYSTEM:
the SWRGM-48 has a built-in audio level adaptor that
outputs the proper audio level from the aftermarket radio to
8-pin connector on the SWRGM-48 harness to the GRAY
module is also labeled “Bose” and “Non Bose” to avoid
confusion. (see picture below)
system, plug in the male 8-pin connector to the BLACK
female 8-pin on the SWRGM-48 module.
BOSE
NON BOSE
RED to SWC Key 1
WHITE to SWC Key 2
SHIELD to SWC Ground
rev.070124
SWC Troubleshoot option
Located internally
Need to take plastic
Casing o module
• If Steering Wheel Controls don’t
work or work properly please switch
internal dip switch from 3v3 to 5v
as shown in picture above.
A 91311
.cruxinterfacing.com
SWRGM-48
Radio Replacement Interface with Steering Wheel Control
Retention for select GM Class II Vehicles
3 of 8
R O P LA TADI RE CEM EN
SW E T IONC R ENT
+
R
INTERFACING SOLUTIONS
CHIME VOLUME ADJUSTMENT:
STEERING WHEEL CONTROL BUTTON FUNCTIONS:
Preset
NOTES:
4 BUTTON SWC
ALPINE
4 BUTTON SWC
CLARION
Preset Up
rev.070124
SWC Bu on
SHORT PRESS
LONG PRESS
SWC Bu on
SHORT PRESS
LONG PRESS
SWC Bu on
SHORT PRESS
LONG PRESS
