OWNER’S MANUAL
6 x 9-inch (150 x 230 mm) 2-Way Component System
Thank you for choosing JL Audio loudspeakers for
your automotive sound system.
We strongly recommend that you have your new loudspeakers installed by
an authorized JL Audio dealer. Your authorized dealer has the training,
expertise and installation equipment to ensure
optimum performance of these loudspeakers in your vehicle.
If you decide to install the loudspeakers yourself, please read this manual
thoroughly to familiarize yourself with their installation
requirements and setup procedures.
Should you have any questions regarding the instructions in this manual,
please contact your authorized JL Audio dealer for assistance, or call the
JL Audio Technical Support Department at (954) 443-1100
during business hours (USA - Eastern Time Zone).
2 | JL Audio - C1-690 Owner’s Manual
A
C
A
B
B
B
Due to ongoing product development, all specifications are subject to change without notice.
Woofer Physical Dimensions
Frame Outer Diameter (A) 6.38 x 9.33 in. / 162 x 237 mm
Motor Outer Diameter (B) 3.54 in. / 90 mm
Mounting Depth (C) 2.75 in. / 70 mm
B
A
D
C
A
D
B
A
C
Crossover Network Physical Dimensions
Width (A) 1.96 in / 50 mm
Height (B) 0.90 in / 23 mm
Depth (C) 1.34 in / 34 mm
Tweeter Fixture Physical Dimensions Flush-Mount Surface-Mount
Fixture Outer Diameter (A) 1.97 in / 50 mm 2.01 in / 51 mm
Fixture Mounting Hole Diameter (B) 1.75 in / 45 mm N/A
Fixture Mounting Depth (C) 0.40 in / 10 mm N/A
Tweeter Frontal Protrusion (D) 0.32 in / 8 mm 0.87 in / 22 mm
