owner’s manual

6.50-inch (165 mm) Convertible 2-Way Component System

Thank you for choosing a JL Audio Evolution™ C3 Convertible

Component System for your automotive sound system.

These Evolution™ Speakers have been designed and manufactured to

exacting standards in order to ensure years of musical enjoyment in your

vehicle. For maximum performance and extended warranty

coverage, we highly recommend that you have your new speakers installed

by an authorized JL Audio dealer. Your authorized

dealer has the training, expertise and installation equipment to ensure

optimum performance from this product. Should you

decide to install the speakers yourself, please take the time

to read this manual thoroughly so as to familiarize yourself

with its installation requirements and setup procedures.

If you have any questions regarding the instructions in this

manual or any aspect of your amplifier’s operation, please contact your

authorized JL Audio dealer for assistance. If you need further assistance,

please call the JL Audio Technical Support Department

at (954) 443-1100 during business hours.

2 | JL Audio - C3-650 Owner’s Manual

Woofer Physical Dimensions

Frame Outer Diameter (A) 6.50 in. / 165.1 mm

Grille Tray Outer Diameter (B) 6.74 in. / 171.2 mm

Rear Cover Outer Diameter (C) 4.08 in. / 103.6 mm

Frontal Tweeter Protrusion* (D) 0.75 in. / 19.1 mm

Frontal Grille Protrusion (E) 1.03 in. / 26.2 mm

Mounting Hole Diameter (F) 5.56 in. / 141.2 mm

Mounting Depth (G) 2.55 in. / 64.8 mm

Crossover Network Physical Dimensions

Height (A) 4.72 in. / 119.9 mm

Width (B) 3.36 in. / 85.3 mm

Depth (C) 1.44 in. / 36.6 mm

Tweeter Fixture Physical Dimensions Flush-Mount Surface-Mount

Fixture Outer Diameter (A) 2.12 in. / 53.8 mm 1.93 in. / 49.0 mm

Fixture Mounting Hole Diameter (B) 1.875 in. / 47.6 mm N/A

Fixture Mounting Depth (C) 0.71 in. / 18.0 mm N/A

Tweeter Frontal Protrusion (D) 0.32 in. / 8.1 mm 0.95 in. / 24.1 mm

Produkspesifikasjoner

Merke:	JL Audio
Kategori:	Høyttaler
Modell:	C3-650
Impedans:	4 Ω
Toppeffekt:	225 W
Diskanthøyttaler:	Ja
Nominell effekt:	75 W
Forsterker inkludert:	Nei
Separate komponenter:	Ja
Subwoofer inkludert:	Nei
Høyttaler type:	2-veis
Basshøyttalerens diameter:	165 mm
Diskant diameter:	25 mm
Innbygningsdybde:	65 mm
Diameter for monteringshull:	141 mm
