Planet BSP-115PV-15A Bruksanvisning
Les nedenfor 📖 manual på norsk for Planet BSP-115PV-15A (40 sider) i kategorien Bryter. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/40
5-Port Solar PoE Switch with 1-Port 1000X SFP
BSP-115 Series
User's Manual
Table of Contents
1. Package Contents ..........................................................................................3
1.1 Packet Contents ......................................................................................4
1.2 Product Description .................................................................................4
1.3 Product Features .....................................................................................8
1.4 ProductSpecications ............................................................................ 11
2. Hardware Introduction ................................................................................. 16
2.1 BSP-115HP-5A ...................................................................................... 16
2.1.1 BSP-115HP-5A Front Panel ........................................................... 16
2.1.2 BSP-115HP-5A Rear Panel ............................................................ 17
2.1.3 BSP-115HP-5ALEDDenition ....................................................... 19
2.2 BSP-115PV-15A .................................................................................... 22
2.2.1 BSP-115PV-15A Front Panel ......................................................... 22
2.2.2 BSP-115PV-15A Rear Panel .......................................................... 23
2.2.3 BSP-115PV-15ALEDDenition: .................................................... 25
2.3 Wiring the Power Inputs ........................................................................ 28
2.4 Grounding the Device ............................................................................ 30
3. Installation .................................................................................................. 31
3.1 Wall-mount Plate Mounting .................................................................... 31
3.2 Hardware Installation ............................................................................ 32
3.3 Installing the Solar PoE Switch ............................................................... 32
3.4 Installing Battery .................................................................................. 32
3.5 Installing PV Panel ................................................................................ 34
3.6 Installing DC Power ............................................................................... 35
4. Smart LCD Screen Description ...................................................................... 36
4.1 SmartLCDscreendescription(BSP-115PV-15Aonly): .............................. 36
5. Customer Support ....................................................................................... 38
AppendixA:RecommendedUseoftheConnectedWires ..................................... 39
3
1. Package Contents
ThankyouforpurchasingPLANETBSP-115HP-5A and BSP-115PV-15A Solar PoE
Switches.ThedescriptionsofthisBSP-115seriesareasfollows:
BSP-115HP-5A 5-Port Hybrid PoE Solar PoE Switch with 1-Port 1000X SFP
BSP-115PV-15A
5-Port 802.3at PoE+ Solar PoE Switch with 1-Port 1000X SFP and
LCD Display
Thehardwarespecicationsofthesemodelsareshownbelow:
Item
ModelName
10/100/1000T
RJ45 Ports
100/1GX
SFP Slots
PoE Ports LCD Power Input
BSP-115HP-5A 5 1 5 -- PV/DC/BAT
BSP-115PV-15A 5 1 5 1.1-inch PV/BAT
Inthefollowingsections,theterm“Solar PoE Switch”referstotheBSP-115HP-5A
or BSP-115PV-15A.
Produkspesifikasjoner
| Merke: | Planet |
| Kategori: | Bryter |
| Modell: | BSP-115PV-15A |
