Planet GSW-1820HP Bruksanvisning

Planet Bryter GSW-1820HP

Les nedenfor 📖 manual på norsk for Planet GSW-1820HP (19 sider) i kategorien Bryter. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/19

16-/24-/48-Port 10/100/1000T 802.3at PoE +

2-/4-Port 1000X SFP Gigabit Ethernet Switch

GSW-1820HP/GSW-2620HP/GSW-5240HP

User's Manual

Table of Contents

1. Package Contents ..........................................................................................5

2. Product Features............................................................................................6

3.ProductSpecications ....................................................................................8

4. Hardware Introduction ................................................................................. 11

4.1 Front Panel ........................................................................................... 11

4.2 LED Indicators ...................................................................................... 11

4.3 Multiple Functions of DIP Switch ............................................................ 13

4.4 Rear Panel ........................................................................................... 15

5. Hardware Installation ................................................................................... 16

5.1 Rack Mounting ...................................................................................... 16

5.2 Installing the SFP Transceiver ..................................................................... 18

Customer Support ............................................................................................ 19

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp.

All other trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all

environments and applications, and makes no warranty and representation, either

implied or expressed, with respect to the quality, performance, merchantability, or

tnessforaparticularpurpose.

PLANEThasmadeeveryeorttoensurethatthisUser’sManualisaccurate;PLANET

disclaims liability for any inaccuracies or omissions that may have occurred.

Information in this User’s Manual is subject to change without notice and does not

represent a commitment on the part of PLANET. PLANET assumes no responsibility

for any inaccuracies that may be contained in this User’s Manual. PLANET makes

no commitment to update or keep current the information in this User’s Manual,

and reserves the right to make improvements to this User’s Manual and/or to the

productsdescribedinthisUser’sManual,atanytimewithoutnotice.

Ifyoundinformationinthismanualincorrect,misleading,orincomplete,wewould

appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the Instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his

own expense.

CE Mark Warning

This device is compliant with Class A of CISPR 32. In a residential environment this

equipment may cause radio interference.

Produkspesifikasjoner

Merke:	Planet
Kategori:	Bryter
Modell:	GSW-1820HP
Vekt:	2670 g
Bredde:	440 mm
Dybde:	208 mm
Høyde:	44 mm
LED-indikatorer:	Activity, LAN, Link, PoE, Power
Strømforbruk (maks.):	270 W
Sertifisering:	FCC 15 A, CE
Nettverksstandard:	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Auto MDI/MDI-X:	Ja
10G støtte:	Nei
Varmespredning:	921 BTU/t
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Jumbo rammer:	9216
Fiberoptisk kontakt:	MiniGBIC, SFP
Produktfarge:	Blå
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Lagringsrelativ fuktighet:	5 - 95
Formfaktor:	1U
Kroppsmateriale:	Metall
Relativ luftfuktighet under drift (H-H):	5 - 95
Rack-montering:	Ja
Svitsjtype:	Uhåndtert
Antall Basic switching RJ-45 Ethernet-ports:	16
Basic switching RJ-45 Ethernet ports-type:	Gigabit Ethernet (10/100/1000)
Strømningskontroll støtte:	Ja
Størrelse på adressetabell:	8000 oppføringer
Ruting/svitsjekapasitet:	36 Gbit/s
Strøm over Ethernet (PoE):	Ja
Power over Ethernet (PoE) effekt per port:	30 W
Antall Power over Ethernet plus (PoE+)-ports:	16
Antall vifter:	2 vifter
Jumbo Frames-støtte:	Ja
Full tosidig:	Ja
Strømforsyning via Ethernet/Power over Ethernet (PoE):	52 V
Fibre Channel-porter:	2
Total Power over Ethernet (PoE)-budsjett:	240 W
Innput-strøm:	5 A
VLAN støtte:	Ja
Lagre-og-videresend:	Ja
MAC-adresse automatisk læring støttes:	Ja
MAC-adresse automatisk aldring støttes:	Ja
Ethernet-fiberkabelteknologi:	1000BASE-X
Gjennomstrømming:	26.8 Mpps
