Side 1/4
1 9471003
CAUTION: To reduce the risk of electric shock,
Do not remove cover. No user serviceable parts inside.
Refer servicing to qualified service personnel.
Do not expose this apparatus to rain or moisture. Apparatus shall
not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ISSUE 1
ezIP 24 PORT ONE-WAY GATEWAY
EZ-GW24
INTRODUCTION
The EZ-GW24 One-Way Gateway is designed for
applications using analog 25 Volt, 45 Ohm or Self-
Amplified speakers. The EZ-GW24 is ideal for
modernizing existing analog paging systems. The
EZ-GW24 One-Way Gateway supports 24 paging
zones. The EZ-GW24 uses Valcom’s ezIP
protocol but can be upgraded to VIP protocol for
compatibility with standard Valcom IP products.
SPECIFICATIONS
Features
24 Zone/Speaker Connections
Zone output can be programmed for 25 Volt
speakers, 45 Ohm speakers or Line Level
RJ-45 for network connection
Front panel activity LED
Compatible with Valcom ezIP Protocol,
upgradable to Valcom VIP Protocol
Dimensions/Weight
1 Standard 19” Rack Unit
1.75” H x 16.50" W x 15.0" D
(4.5cm H x 41.9cm W x 38.1cm D)
Weight: 6.20 lbs. (2.8 kg)
Nominal Specifications
Zone Outputs 45 Ohm Impedance
Line Level Output -10 dBm
Nominal Power Requirements
100-240Vac, 2.5A, 50/60Hz
These products use an internal UL Listed power
source rated 24VDC.
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Precautionary Designations
WARNING-To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
• AVERTISSEMENT - Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.
Apparatus shall not be exposed to dripping
or splashing and no objects filled with
liquids, such as vases, shall be placed on
the apparatus.
• L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et aucun
Objet Rempli de liquide, comme vase, ne
doit être placé sur l’appareil.
2 9471003
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses and can radiate radio
frequency energy and if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment
in a residential area may cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
INSTALLATION
Mounting
The EZ-GW24 is designed for rack mounting (1U).
Confirm mounting brackets are firmly attached to
the EZ-GW24. Place the EZ-GW24 into a
standard 19” rack and secure to rack with proper
hardware. (Figure 2)
Power Connections
Make sure all signal connections via the back
panel are made and the EZ-GW24 is connected to
the Ethernet switch, then connect the power cord
to the AC power source. A strain relief bracket is
provided to secure the AC cord. (Figure 4)
Front Panel Connections (Figure 5)
Network Connection
The EZ-GW24 has an RJ45 Ethernet network
connection on the front panel.
The Ethernet connector has two LEDs to indicate
link speed and activity.
Left LED (Amber) indicates Activity:
Flashing indicates packets sent/received
Right LED (Green) indicates link:
On steady: Connected
Status LED
The Status LED on the front panel indicates the
general status of the EZ-GW24. (Figure 5)
Off: Indicates system startup or not powered on
Red Flashing: Indicates system is ready
SPEAKER CABLING
If this EZ-GW24 is installed to replace an existing
page controller, please be aware the primary
cause of troubles in retrofit systems is directly
related to the existing field wiring.
It is imperative that existing speaker wiring (field
wiring) be assessed before making connections to
new equipment.
Always check speaker lines, new or existing, for
transient voltage and proper impedance before
cross connecting to the intercom equipment. Use
a good quality Impedance Meter, not an Ohm
meter.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chiffon sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplificateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not fit into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la fiche polarisée ou de mise à la terre. Une
fiche polarisée possède deux lames dont une plus large que l'autre. Une fiche de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la fiche fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
N'utilisez que des fixations / accessoires spécifiés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specified
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécifié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Confiez toute réparation à un personnel qualifié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la fiche est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
