Side 1/5
1 9471004
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
Issue 1
ezIP High Power One-Way Paging Horn
EZ-HR15-GY
INTRODUCTION
The EZ-HR15-GY ezIP One-Way Paging Horn
is a weather-resistant, high-efficiency horn
supporting SIP (Session Initiation Protocol) and
Valcom’s ezIP paging protocol, delivered via a
PoE-enabled IP network. The high-impact
Polycarbonate construction resists the
deteriorating effects of outdoor installation.
SPECIFICATIONS
Access Methods
• SIP telephone system
• Valcom ezIP Page Controller
• Valcom ezIP Interactive Console
• Valcom ezIP Multicast Page Group
Features
• Indoor / Outdoor use
• High Impact Polycarbonate Housing
• Omni-Directional Mounting Base
• SIP & Multicast Enabled
• Power over Ethernet (PoE) 802.3af and
802.3at (PoE+) compatible
• Remote Management & Monitoring
• Upgradable to full Valcom IP capability,
including full-duplex talkback
communication
Dimensions / Weight
• 11.75” H x 10.0” W x 11.0” D (29.8cm H x
25.4cm W x 27.9cm D)
• 4.3 lbs. (1.95 kg)
Audio Codecs
• G.722, G.711 (uLaw, aLaw)
Frequency Response
• 350 Hz to 7kHz
Audio Dispersion
• 120° Horizontal
• 90° Vertical
Nominal Power Requirements
IEEE 802.3af (PoE) Class 3
IEEE 802.3at (PoE+) Class 4
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24 Vdc, or 48 Vdc (PoE).
PoE and all interconnected ITE are intended for
intra-building.
Environment
Temperature: - 20° to +50° C
Humidity: 0 - 95% non-condensing
