DUAL NETWORKED
PAGE ZONE EXTENDER
MODEL VIP-802
Valcom, Inc. 5614 Hollins Road Roanoke, Virginia 24019 Phone: 540-563-2000 Fax: 540-362-9800
E-Mail: info@valcom.com www.valcom.com
Page 1
Technical Specification
FEATURES:
2 Audio Outputs
2 Audio Inputs
2 Form A relay Contacts
2 Contact Closure Inputs
RJ-45 For Network Connection
Front Panel Activity LED
Provides Audio For Up To 40 Valcom One-
way Amplified Speaker Assemblies
Aux Audio Input Via RCA Jack
Contact Closure Or VOX Operation Of
Audio Input
Page With Music Output, Music Mutes
During Page
Output Control Contact Closure Provided
During Paging Output
Compatible With 25 Or 70 Volt Amplifiers
2.5mm Jack For DC Power
Power Over Ethernet 802.3af Compliant
No Server Required
1 to 11 Digit Dial Plans
Easy Windows Based Setup
DESCRIPTION:
The VIP-802 Dual Networked Page Zone Extender enables voice access to two zones of one-way paging over an IP-
based LAN/WAN. This allows page zone extension anywhere on the network. Multiple VIP-802 Dual Networked Page
Zone Extenders can be used on the same network to create very large and distributed public address systems.
Example applications include: Multiple floors in a single building, Multiple buildings in a campus environment, City wide
paging of all Fire & Rescue buildings, Interstate paging between bank branches.
Specifications:
Nominal Specifications
Input Impedance: 600 Ohms
Input Level: -10dBm nominal
Voice Switch Sensitivity: -21dBm
Music Source Input Impedance: 8 to 600 Ohms
Music Input Level: -10dBm nominal
Output Impedance: 50 Ohms
Output Level: - 10dBm nominal
Relay Current: 1 AMP @ 24VDC
Protocols: DHCP, IGMP v3, UDP, TCP, HTTP,
Telnet, FTP
Voice Algorithm:
G.711 (64kbits/s) (ulaw)
Echo Suppression
Nominal Power Requirements
Via back panel barrel connector:
Voltage: 24VDC
Current: 325mA
Via 802.3af PoE Ethernet Switch:
802.3af: Class 3
Environment
Temperature: +32 to +104 °F (0 to +40 °C)
Humidity: 0 to 85% non-precipitating
Dimensions/Weight
1.75 "H x 6.75 "W x 9.5 "D ( 4.445 cm x 17.145 cm x 24.13 cm)
Weight: 1.75 lbs. (0.79 kg)
ShippingWeight:3.0lbs ( 1.35kg)
